Product Specifications
Prod Model: |
MR6-300 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Ss304: |
Preformed Pouch Packing Machine |
Rotary Bag Gaven Filling And Sealing: |
Zipper Bag Open Close Equipment |
Automatic Grade: |
Fully Automatic |
Structure: |
Linear |
Feed Cylinder Structure: |
Multi-Room Feeding |
Material Type: |
Granular |
Type: |
Volumetric Filling Machine |
Filling Valve Head: |
Multi-Head |
Packaging Container Lifting Structure: |
Chute Lifting |
Filling Principle: |
Atmospheric Pressure |
Packaging Type: |
Bag |
Dosing Device: |
Capacity Cup |
Packaging Material: |
Film |
Product Description
Pouches type:
All kinds of preformed side spout pouches and bottom seal spout pouches
Applications:
1. Liquid: Rice wine, soy sauce, rice vinegar, fruit juice, beverage, detergent, etc.
2. Thick liquid: Tomato sauce, peanut butter, jam, chili sauce, bean paste, etc.
Main Features:
Suitable pouches: All kinds of preformed side spout (corner spout) pouches and bottom seal spout pouches.
Wash-down: Direct water-washing the machine surface, so timely clean up the corrosive material, to enhance the hygienic and safety, to prolong the useful life.
Easy to operate: PLC controller and color touch-screen, fault indication on the touch screen.
Easy to adjust: Only about 10 minutes to change different pouches.
Frequency control: Speed can be adjusted by frequency conversion within the range.
High Automation: Unmanned in weighing and packing process, machine alarm automatically when failure.
Waterproof design: The machine surface can be washed down, so easy cleaning, and longer useful life.
Safety and Hygiene:
1. No pouch/ incorrect pouch opening-no fill-no seal, machine alarm.
2. Machine alarm and stop when the inadequate air pressure.
3. Safety guards with safety-switches, machine alarm and stop when the safety guards are opened.
4. Hygienic construction, the product contact parts are adopted SUS304 stainless steel.
5. Imported engineering plastic bearings, no need to oil, no contamination.
6. Oil-free vacuum pump, avoid the pollution of the production environmental.
Specifications and Parameter
Bag types All kinds of preformed corner spout bags and bottom seal spout bags
Model |
MR6-300 |
No. of working station |
Six |
Function |
Bags dispensing, Coding, Opening, Dosing, Heat sealing, bags discharge |
Bags size |
W200-300mm L: 100-450mm |
Filling Volume |
100-3000g(depending on type pf product) |
Packaging Materilas |
Preformed side seal bags, Zipper bag, stand-up bag, spout bags etc |
Capacity |
25-40bags/min(depending on type of product and packaging material used) |
Total power |
3Kw |
Machine weight |
Approx 1.500Kgs |
Dimension |
1740*1540*1765mm |
Compress air |
0.5m 3 /min to be supplied by user |
Wenzhou ECHO machinery Co; Ltd establish in 2010, is located in the important birthplace of zhe nang mode-Ruian. The company is specialized in automatic given bag packing machine and vacuum packing machine. ECHO packing machinery is a National high and new technology company combined with research, manufacturing, marketing and service, and possess the largest research and development institutions in the domestic industry, perfect production system and huge marketing service network, annual output and market share all reside the ex-row in profession.
At present, the company marketing network through the country, and exported to Europe, America, Southeast Asia, West Asia, the Middle East and other dozens of countries and regions. Our various products are applied in food, medicine, commodities, chemical industry, pesticides and other industries.
The company take "superior quality, user first, excellent service, continuous improvement" as guidance. To making incessant innovations on behalf of their customer for the mission. And in the first place through the IS09001 quality management system certification and CE certification in the industries. In the future, ECHO will develop in depth in for ares: " Technology, institution, management and culture. " With outstanding product quality and good market reputation to meet customer' S inspection!
