Product Specifications
| Prod Model: |
ZL20F |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Engine: |
4105 |
| Rated Load: |
2000kg |
| All Colors: |
Best Price |
| Type: |
Small Loader |
| Certification: |
CE |
| Walking Mode: |
Wheeled |
| Condition: |
New |
| Load And Unload Method: |
Front Discharge |
Product Description
WHEEL LOADER 2Ton with CE ZL20F
Performance
1. Rated loading: 2000kg
2. Overall weight: 5800kg
3. Rated bucket capacity: 1.1m3
4. Maximum tractive force: 54KN
5. Maximum breakout force: 45.4KN
6. Maximum grade ability: 30
7. Maximum dump height: 3000mm
8. Maximum dump reach: 752mm
9. Overall dimension (L× W× H): 5633× 2120× 2712mm
10. Minimum turning radius: 5251mm
Engine
11. Model: R4105G57
12. Type: Vertical, in-line, water cooled, 4-stroke diesel engine
13. No. Of cylinder-bore/stroke: 4105× 125mm
14. Rated power: 55kw2200r/min
15. Maximum torque: 270N. M
16. Min fuel-consume ratio: ≤ 243G/kw. H
Transmission system
17. Torque converter: YJ280A
18. Gearbox mode: Countershaft power-shift
19. Gear shift: 2 forward shift 2 reverse shift
20. Maximum speed: 24km/h
Drive axles
21. Main reducing spiral: Circular Arc Bevel gear, single stage
22. Decelerating mode: Single stage planetary type
23. Wheel base (mm): 2400mm
24. Wheel tread: 1640mm
25. Ground clearance: 310mm
Hydraulic system
26. System working pressure: 16MPa
27. Boom lifting time: 4.8s± 0.2s
28. Total time: 9.2s± 0.5s
29. Fuel tank capacity: 80L
30. Function of leveling automatically: Yes
Brake system
31. Service brake: Air assist disc brake on 4 wheels
32. Parking brake: Flexible shaft operated external drum
Tyre
33. Type specification: 16/7020
34. Front tyre pressure: 0.22Mpa
35. Rear tyre pressure: 0.18Mpa
