Price: | Negotiable/Piece |
---|---|
Trade Terms: | FOB |
Min Order: | 300/Piece |
Pay Type: | L/C,T/T |
Prod Model: | B-15 |
---|---|
Markets: | Eastern Europe,Southeast Asia,Mid East,Western Europe |
Size: | 120X46X31mm |
Output Voltage: | 5V, 12V, 24V |
Output Type: | Dual |
Warranty: | 1 Year |
Output Power: | 15W |
Input Voltage: | 176-264VAC |
Brand: | Czcl |
Product Model:B-15
15W Dual Output Switching Power Supply
Low cost, high reliability
Built-in EMI Filter
Low output ripple&noise
Protections: Over load/ Short circuit
1 year warranty
Case: 801 Size: 120*46*31mm
AC Input voltage range............................. 176-264VAC
Input frequency............................................47-63Hz
AC Inrush current.........................................Cold start, 40A/ 230VAC
DC adjustment range....................................V1:±5% rated output voltage
Line regulation(full load)................................≤0.5%
Output over load protection...........................110%-150% hiccup mode, auto-recovery
Rise, hold up time..........................................50mS, 20mS at full load (typical)
Withstand voltage...........................................I/P-O/P, I/P-FG: 1.5KVAC, O/P-FG: 0.5KVAC,1 min
Working temperature...................................-10ºC~ +40ºC@100%, +60ºC@ 60% load
Storage temperature......................................-20ºC~+85ºC, 20 %-95%RH (non-condensing)
Safety standards.............................................Design refer to GB4943,UL60950-1,EN60950-1
EMC standards...............................................Design refer to GB9254,EN55022 class A
Cooling method...............................................Free air cooling convection
Product model | DC output | Load regul. | R&N | Efficiency |
B-15P | 5V, 0.2-2A | 2% | 100mV | 70% |
12V,0-0.4A | 5% | 120mV | ||
B-15R | 5V, 0.2-2A | 2% | 100mV | 70% |
24V, 0-0.2A | 5% | 200mV |
