Product Specifications
| Prod Model: |
LFIP-STW-JET320SW |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
LFIP-STW JET320SW series are solvent wide format printers, they use Spectra Skywalker128/50PL printhead.
Characteristics:
--Advanced Spectra skywalker printhead technology offers fast and outstanding quality printing
--Use wave printing technology
--Steel-made nozzle ensures ever long life of printhead
--Use three-way valve, auto printhead cleaning system
--Auto blank-jump function.
--Jetting frequency as high as 16KHz
--Steadiness of performance ensures least probability of breakdown
--Economic stander model with tremendous performance
--Spectra Skywalker128/50PL printhead
--Perfect expression to high resolution with amazingly low production cost
|
Product Model |
LFIP-STW-JET320SW |
|
Print Technique |
Spectra Skywalker128/50PL Piezo electric printhead, 12heads inside |
|
Color Quality |
Photo Quality/Two Level (General, High)/X, Y are all grating location print. |
|
Max Media Width |
3300mm |
|
Max Printing Width |
3250mm |
|
Output( m 2 /H) |
Mode |
Output (m2/h) (12printheads) |
|
2pass |
108 |
|
3pass |
98 |
|
4pass |
52 |
|
6pass |
26 |
|
Display |
LCD display with 8 key panel, self-diagnosis available |
|
Ink Type |
Solvent-base ink: C, M, Y, K |
|
Ink Supply Mode |
auto ink supply by electric pump, volume of main tank 1000 ml/color |
|
Ink Inspection System |
Auto/manual ink supply, low ink detector |
|
Printing Driver |
Support many RIP drivers |
|
operation platform |
Support many operation platforms (Window2000, NT, XP etc) |
|
Media Type |
Flex, vinyl, window film, polyseter, etc |
|
Media Input |
Roll media or sheet media |
|
Media Processing |
Auto feeding and take-up system, weight less than 60 kg/rol |
|
Print head Height |
2 mm-3 mm above media adjustable |
|
Pre-heater & Dry System |
Front-rear temperature control, Max temperature 65° C, Cold wind dry system |
|
Clamp |
Manual adjustment media width |
|
Print head Cleaning System |
Manually positive pressure cleaning and flush solution cleaning |
|
Safety System |
Inside safety lock with auto shutting down function |
|
Print Interface |
USB 2.0 Ports(Window 2000, NT, XP etc) |
|
Noise |
Printing status≤ 60 dB/waiting status≤ 40 dB |
|
Printer Size (including ink tank) / Net Weight |
L4826mm * W906mm * H1185mm/340 KG |
|
Package Size / Weight |
L4840mm * W960mm * H1294 mm/378 KG |
|
Heating& Controlling Voltage |
AC 220V/50HZ, AC 110V/60HZ Optional |
|
Input Media Voltage |
AC 220V/50HZ, AC 110V/60HZ Optional |
|
POWER (AC 220V Hour) |
Controlling: less than 3A Heating: less than 5A Expanding Media: less than 5A |
|
Working Environment |
Temperature: 20° C∼ 30° CHumidity: 40% ∼ 80% |
|
Difference |
JET320SW: Cold wind dry system, double-round guide.
JET320SW+: Cold wind dry and Infrared heating system, THK straight line guide, Auto feeding and take-up system |
