Product Specifications
Prod Model: |
LFIP-MJT-LB3208KM42 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
Japan Konica 512 42PL Printhead.
Separate ink pressure system, saving ink and decreasing the cost of the clients.
Ink temperature system.
Large print platform design, can install different quantity printhead, it is easy and convinient to upgrade.
The carriage's height can be adjusted easily.
Photoelectricity sensor and automatic correction system.
The platform use suction turbine fan, the wind of which is stronger 200% than the ordinary one, strong suction platform can ensure the material doesn't touch the printhead.
Three-heating system: Pre-heater, printer heater, and after heater, printhead heater, adjust the suitable temperature of the media, increase the printing quality.
Large platform heating after printing, can increase the drying speed.
Printhead heating, can enable the printer to print in low temperature.
Two row dry-fans, can make the printed picture dry quickly, enable it can be rolled up quickly.
PACKING SIZE: 4760*950*1450mm
Net Weight/Gross Weight: 650KG/750KG
Model |
LB3208KM42 |
Printing Type |
Separation Printing |
Printing Technology |
Piezo printing |
Printhead Type |
KM 512/42PL head (8 printheads) |
Media Transmmision |
Roll to Roll |
Printing Port |
High speed USB boards |
Data Transmission |
Fabric Cable |
Output Model |
Rip Printing/Printing After RIP/Net-print |
RIP Software |
Photoprint, Maintop, Ultraprint |
Printing Mode |
4 Colors with 8 printheads |
Speed |
High speed: |
180*720dpi: 70 m 2 /h 2pass |
Mid speed: |
240*540dpi: 58 m 2 /h 3pass |
Low speed: |
360*1440dpi: 45 m 2 /h 4pass |
Heating System |
Four Heaters: front heater+bed heater+rear heater+printhead heater |
Cleaning System |
Air Pressure and Suction Cleaning |
Frame Structure |
Steady steel structure is used on the machine body, and the combination of aluminum and steel on the girder |
Color |
C, M, Y, K |
Power Requirement |
220V AC |
System |
220V± 10%, < 4A, 50/60HZ |
Heating |
220V± 10%, < 16A, 50/60HZ |
Operation Environment |
Temperature: 20° C∼ 25° C; Humidity: 40%∼ 70%RH |
Printing Resolution |
Ajustable(From 240dpi, 360dpi to 1440dpi) |
Media Types |
Banner, Adhesive Vinyl, PVC Self-Adhesive, Backlit Film, Flex media within 5mm thickness |
Printing/Media Width |
1800mm, 2500mm, 3200mm |
