Product Specifications
| Prod Model: |
LGRD |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Pole Number: |
2p.4p |
| Structure: |
MCB |
| Poles Number: |
2 |
Product Description
2P 20A New type Good Protection LGRD Residual Current Circuit Breaker
Application:
The item is in comply with standard of IEC61008-1, applying to the circuit of AC 50/60Hz, 230V, single phase, 400V three phases or below it for industrial and mining enterprise, trade building, commerce and family. It is mainly used for preventing electric fire and personal casual accident caused by personal electric shock or leakage of electrified wire net, this is a current operated, fast leakage protector of pure electromagnetic type, which can break off fault circuit rapidly in order to avoid occurrence of accident. The item is precise in structure, less elements, without auxillary power and high working reliability. The fuction of the switch won't be influenced by ambient temperature and lighting. The mutual inductor of the item is used to test vector differential value of passing current, and produces a relevant output power and add it to the tripper in secondary widing, if the current of vector differential value of protected circuit of personal electric shock is up to or over leakage operating current, the tripper will act and cut off so that the item will take effect of protection.
| Number of poles | 2p 4p |
| Rated current | 16.20.25.32.40.50.63 |
| rated residual operating current | 300.100.300.500 |
| rated residual non-operating current | <0.5 |
| rated voltage | ac 230/400 |
| residual current off-time | <0.1s |
| short circuit capacity | 3000A |
| endurance | >4000 |
| protection degree | IP20 |
