4 Color High Speed Flexo Printin Machinery
| Price: |
Negotiableset |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1set |
| Pay Type: |
L/C,T/T |
Product Specifications
| Prod Model: |
YT4800 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Colors: |
4 Color |
| Product Name: |
Flexographic Printer |
| Model: |
Yt4800 |
| Printing Length: |
7.5-40 |
| Printing Plate Lifting System: |
Pneumatic/Hydraulic Press Control |
| Mechanical Speed: |
80m/Min |
| Printing. Speed: |
60m/Min |
| Anilox Cylinder: |
10-120dk |
| Register Precision: |
0.25 |
| Dimension: |
4.8*2.05*3.2 |
| Plate: |
Relief Printing |
| Type: |
Ink Jet |
| Embossing Structure: |
Rotary Letterpress |
| Color & Page: |
Multi-Colour Printing Press |
Product Description
Name: 4 color flexo printing machineUse:
Anilox inkig: with ceramic anilox the line number 100PLI to the 1000PLI high speed dot reproduction rate, screeen printing structure, three-dimensional sense of strong, accurate registering.
Ink: automatic circulaion system, the ink line using a single motor.
speed:frequency control, running small fluctuations.
unwining correcton: the high-grade automatic optical correction control system.
ink way:the company's unique design scraping knife scraping in with ink pump ink device automatically.
from the verson drop-version: hydraulic automatic up and down version
smooth roll: special steel processing, and through a special process, and the protective layer of hard
chrominum plating thickness of 10 silk. beating 0.02mm.
a chain guide roller:semi-enclosed bearing in Japan, do static balance and dynamic balance processing, hard oxidation treatment sesistance, beating small.| Prinint width | 600mm | 800mm | 1000mm | 1200mm | 1400mm | 1600mm | 1800mm | 2000mm |
| Printing color | 6 special color |
| Printing length | 7.5"-40" |
| Printing plate lifting system | Pneumatic/hydraulic press control/menu |
| Mechanical speed | 100m/min |
| Printing speed | 80m/min |
| Anilox cylinder | Metal:10DK-120DK(Germany) |
| Register precision | Longitude: ±0.25mm, transverse: ±0.25mm |
| Rewinder/unwinder dia | 600mm |
| Master motor | 5.5kw | 5.5kw | 7.5kw | 7.5kw | 11kw | 11kw | 15kw | 15kw |
| Rewinder motor | 5.5kw | 7.5kw |
| Unwinding motor | 3.7kw | 4.0kw | 5.5kw | 7.5kw |
| Electrical heater | 25kw | 28kw | 32kw | 38kw |
| Blower of nature winder | 0.75kw | 1.1kw | 1.5kw | 2.2kw |
| Blow of heater | 0.75kw*2 | 1.1kw*2 | 1.5kw*2 | 2.2kw*2 |
| Inking motor | 750w | 1100w |
| Master frequency converter | 7.5kw | 11kw | 15kw | 18.5kw |
| Master power | 42kw | 50kw | 60kw | 75kw |
| Weight | 7150kg | 7350kg | 7550kg | 7800kg | 8050kg | 8300kg | 8700kg | 9200kg |
| Dimension | 6.3*1.8*3.4m | 6.4*2*3.4m | 6.5*2.2*3.4m | 6.6*2.4*3.4m | 6.7*2.6*3.5m | 6.8*2.8*3.5m | 6.9*3.1*3.5m | 7.0*3.4*3.5 |
In the machine field, "Hongguang" has fast developed by study and apply advanced technique. "Hongguang" machinery has passed ISO9001: 2000 international quality system and own imports and exports right. According to the service concept of "cast elaborate, good faith manager". "Hongguang" Machinery provides lifelong maintenance for all the products that it sells.
At the same time, according to the different production conditions and capabilities of different customers, we provide convient, scientific and economic project budget plans. By means of outstanding technical support, and taking into consideration what our customers want, we lead them to the success that they desire. "Hongguang" Machinery's strength relies on management strategy that places service firstand foremost, and management operations that achieve excellent scientific results. We always endeavor to carry forward the spirit of the nation, creat a brand name for the nation.
At the start of the new century, we have put for ward new lines of products that include thansparent film 3D packer, film blowing machine, bag-making machine, and printing machineetc...Our products have seen excellent sales at China, as well as in 30 different regions and countries in Asia, Africa and Europe.
"Hongguang" Machinery are willing to cooperate with friends of various circles at home and abroad, March forward hand in hand and create brillingce again.
