Product Specifications
| Prod Model: |
DDS226D-4P |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Brand Name: |
CNC |
| Model Number: |
Dds226D-4p |
| Display Type: |
Digital Display: Register and LCD |
| Phase: |
Single Phase |
| Accuracy Class: |
1 |
| Output Voltage: |
110V,120V,220V,230V,240V |
| Operating Temperature: |
-25 ~+55 |
| Dimensions: |
75*88*73 |
| Net Weight: |
300g |
| Type: |
Energy Meter |
| Display: |
Digital |
| Electric Equipment: |
Single-phase |
| Theory: |
Electronic Meter |
| Usage: |
Standard Electric Energy Meter |
| Installation: |
DIN-Rial Mount |
Product Description
DDS226D-4PSingle Phase Din-rail Energy Meter
General
DDS226D-4P type single-phase din-rail energy meter can accurately and directly measure 50Hz/60Hz active energy consumption from single phase AC electricity net with functions of good reliability, small volume, light weight, specious appearance, convenient installation, etc. All of the performances accord with the National Standard GB/T17215.321-2008 and International Standard IEC62053-21.
Function and Features
Measuring single phase total active energy power.
May select step motor type impulse register display 5+1 digits (99999.9KWh) or LCD 5+2 digits display, LCD 5+2(99999.99KWh), 5+1 digits(99999.9KWh) and 6+1 (999999.9KWh);
Passive impulse output, comply to DIN43864 Standard;
Two LED indicate power condition and energy impulse signal;
35mm standard DIN rail installation
DDS226D-4P Single Phase Din-rail Energy Meter is a kind of single phase watt-hour meter, electric meter, watt meter, kilowatt meter, electricity energy meter, kwh meter, kilowatt hour meter, din kwh meter, kwh metering.
|
Technical Index |
Specification |
|
Input |
Wiring |
Single Phase |
|
Voltage |
110V/120V/220V/230V/240V |
|
Rated value: 0.8-1.15Un |
|
Power comsumption:0.89W/10VA |
|
Current |
1.5(6)A,2.5(10)A,5(20)A,10(40)A,10(50)A,15(60)A,20(80)A,30(100)A, others can be customized. |
|
Starting current: 0.4%lb |
|
Power consumption:≤2VA |
|
Frequency |
50/60Hz |
|
Accuracy |
±1% |
|
Energy power impulse |
Passive impulse output |
Installation |
Impulse constant: 800-6400imp/kwh |
|
Pulse width: 80ms±5ms |
|
35mmstandard DIN rail mounting |
|
Standard |
GB/T17025.321-2008; IEC62053-21;IEC62052-11;EN50022; DIN43880 |
|
Ambience |
Working temperature: -25 - +55 |
|
|
Storage temperature: -40 - +70 |
|
Relative humidity: 5% - 95% (no condensation) |
|
Altitude: <2500m |
|
Size: 75×88×73(mm) |
|
Net weight: 300g |
