Product Specifications
| Prod Model: |
KMY8500 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Dimension: |
H1500xw540xd500 |
| Monitor Size: |
15", 17", 19" or Above Touch Screen |
| Touch Screen: |
Saw Touch or IR Touch or Upon Clients |
| Supported OS: |
Win7 or Win8 (Test Version) |
| Type: |
Currency Detector |
| Certification: |
CE |
Product Description
FUNCTIONALITIES:
* Dual Screen kiosk: For advertisement and signage
* 24 Hours A Day, 7 Days A Week Sustainable
* 6mm SAW Tempered Touchscreen
* Vandal-Proof Stainless Metal Keyboard
* 80mm Hi-speed Thermal Printer
* Universal 4 Ways cash insertion
* Hi-co Magstripe Card Reader
* Biometric Identification System
* 1D/2D Barcode Scanner
* RFID Card Reader
* 800~1200VA UPS Backup Power Supply
* GPRS Wireless
DESCRIPTION: Customizable Dual-Screen All-Steel Slim and Sleek Multifunction Kiosk with Touchscreen and Wireless Internet Access.
APPLICATION: This kiosk is mainly targeted for use for public positions of varied selfservice and signage points: Retail, finance, hospitality, tourism, health care,
Government, gaming/entertainment, hospitals, restaurants, financial services, wireless access applications, internet terminals, information kiosks, ticket vending
Machinery, cash machinery (ATMs), Internet public phones at shopping malls, universities, hotels, airports, gas stations, railway stations and other public areas.
MAIN FEATURES
* Imposing all steel design, specially designed kiosks meet the highest demands with regard to design, functionality, longevity and high protection level.
We design and manufacture complete functionality modules including controller in close consultation with our customers.
* All steel fascia and enhanced structure guard wilful destruction, vandal-proof, against corrosion, weather-proof especially under extreme climatic
Conditions, water proof/dirt proof, operation under hostile environments.
* Waterproof execution is sealed against the ingress or liquid and dirt.
* The kiosks have excellent shapes and make them eyeball catching to the passengers passing-by.
* Human friendly interface layout: The position of components are designed for a easy access to all the applications with security and convenience.
* Anti-fall layout of components makes it can be safely place in the sites which the anchor points are not allowed. The anchor eyebolts are also
Prepared to have an ensured safety in a lean or hostile environment.
* Ease of customizing with multiple languages, to accommodate foreign or custom variants.
* Easily clean and the painting are very wearable even scratched by a knife.
* To prevent tampering in public application, the whole kiosk can be locked. Various access control systems and temper-detecting devices are also
Available for the crucial applications unsupervised.
DATA SAFETY
* 3DES EPP installed to protect customers' PIN with the latest technology.
* Door lock of maintenance accessible parts.
* Temper detecting alarm devices.
* Remote management system to monitor the status of kiosk.
* The DEL-ALT-CTL key and other functions are blocked to make any attempt access to the operation system almost impossible in win2000/winXP or
High version of MS windows.
ENVIRONMENTAL ADAPTABILITY
* Operating temperature: -10C to +60C.
* Storage temperature: -20C to +70C.
* Operating RH: 30-90%.
* Atmospheric pressure: 60-106Kpa.
* Saline mist: 96 hours, IEC 60512-6.
* Damp heat test at + 40C: 21 days, IEC 60512-6.
* Dry heat test at + 85C: 10 days, IEC 60512-6.
RELIABILITY
* RoHS Compliant, CE and FCC verified.
* Enclosure Protection Level: IP54.
With a special filter in the fans, it can be protected from the dirt and water spray from all the directions.
* Touchscreen Vandal resistant:
With a tempered, 4mm-thickness-glass, these touchscreens can withstand the impact of a 500g steel ball, dropped from a height of 1.3 meters, in accordance
With Trial Standard Number 60950 IEC 1999
* Lifespan >3 years.
* MTBF >50000H.
* MTTR <120min.
| Component s | |
| Host | : Industrial Computer(CeleronD Dothan 420 1.6G , 512M , 80GHDD) |
| Monitor | : Dual 17'' TFT LCD |
| Touchscreen | : 17" SAW 6mm Tempered |
| Thermal Printer | :80mm thermal; Speed: 120mm /s |
| Barcode scanner | :IS3480 Redlight laser scanner |
| Metal Keyboard | :65 Keys KMY299 stainless with trackball |
| Card Swipe Reader | :CRT Hi-CO TK 1,2,3 read(&write, optional) |
| Bill Validator | : P77-PKR7, 4 Way Insertion |
| RFID Reader(optional) | :WASHI RFID card reader |
| Biometric Identifier(optional) | :PW Fingerprint ID system |
| Camera (optional) | :LOGITECH 50M CCD |
| Multimedia | :Bi-channel stereo system |
| Enclosure | :All-Steel Powder-Coated KMY-8500-U11T |
| Wireless (optional) | :BM1206 GPRS Modem |
| OS system (optional) | :Licensed WindowsXP PRO+SP2 |
SZ KMY Co., Ltd. is a leading high-tech company dedicated to R&D, manufacturing, marketing and services in customized self-service computing platforms and related metal keyboard/EPP//POS peripherals. KMY product range covers from self-service kiosk, Metal keyboard/keypad/EPP and POS peripherals, to more other related products. We can provide our customer with one-stop solutions according to their different demands.
KMY defines its strategic goal as "becoming a worldwide leader in the self-service world and achieving leapfrog evolution from excellence to preeminence". To this end, kmy will adhere to its core value: "responsibility makes perfection"and spare no effort to improve its competitiveness by endless development. With its well-built operation system, outstanding organization structure and fully-trained personnel, kmy aims at building an internationalized designer and manufacturer of self-service terminal. The products and solutions are popular both in the domestic and global markets over 100 countries, including America, Europe, Asia, Africa, and the Middle East and won strong reputation in this industry.
