Wall Mounted Multi Functional Touch Screen Kiosk

Product Specifications

Prod Model:	KMY8604E
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Dimension:	H676xw476xd364
Monitor Size:	15", 17", 19" or Above Touch Screen
Touch Screen:	Saw Touch or IR Touch or Upon Clients
Supported OS:	Win7 or Win8 (Test Version)
Type:	Currency Detector
Certification:	GS
Currency Detector Type:	Dynamic Desktop Detector
Currency Detector Principle:	Anti Filling Detection
Queue System Usage:	Indoor
Queue System Display Function:	Graphics
Queue System Type:	Queuing
Data Collector Type:	Rfid Data Acquisition
Data Collector Signal Transmission:	Wired
Data Collector Operating System:	Linux

Product Description

Wall Mounted Multi functional touch screen Kiosk

FEATURES:
* 24 Hours A Day, 7 Days A Week Sustainable
* 4mm Tempered Touchscreen(6mm optional)
* Vandal-Proof TDES Metal PINPad
* 8 Channels Parellel Card Dispensers
* CASHCODE Bill Validator
* Thermal and Dot-matrix Printer
* Magstripe/IC Card Reader
* Biometric Identification System
* RFID Card Reader
* UPS Backup Power Supply

DESCRIPTION: Customizable All-Steel Slim and Sleek Multifunction Kiosk with Touch screen and Wireless Internet Access.

APPLICATION: This kiosk is mainly targeted for use in public areas.

MAIN FEATURES
* Imposing all steel design, specially designed kiosks meet the highest demands with regard to design, functionality, longevity and high protection level.

We design and manufacture complete functionality modules including controller in close consultation with our customers.
* All steel fascia and enhanced structure guard wilful destruction, vandal-proof, against corrosion, weather-proof especially under extreme climatic

Conditions, water proof/dirt proof, operation under hostile environments.
* Waterproof execution is sealed against the ingress or liquid and dirt.
* The kiosks have excellent shapes and make them eyeball catching to the passengers passing-by.
* Human friendly interface layout: The position of components are designed for a easy access to all the applications with security and convenience.
* Anti-fall layout of components makes it can be safely place in the sites which the anchor points are not allowed. The anchor eyebolts are also

Prepared to have an ensured safety in a lean or hostile environment.
* Ease of customizing with multiple languages, to accommodate foreign or custom variants.
* Easily clean and the painting are very wearable even scratched by a knife.
* To prevent tampering in public application, the whole kiosk can be locked. Various access control systems and temper-detecting devices are also

Available for the crucial applications unsupervised.

DATA SAFETY
* 3DES EPP installed to protect customers' PIN with the latest technology.
* Door lock of maintenance accessible parts.
* Temper detecting alarm devices.
* Remote management system to monitor the status of kiosk.
* The DEL-ALT-CTL key and other functions are blocked to make any attempt access to the operation system almost impossible in win2000/winXP or

High version of MS windows.

ENVIRONMENTAL ADAPTABILITY
* Operating temperature: -10C to +60C.
* Storage temperature: -20C to +70C.
* Operating RH: 30-90%.
* Atmospheric pressure: 60-106Kpa.
* Saline mist: 96 hours, IEC 60512-6.
* Damp heat test at + 40C: 21 days, IEC 60512-6.
* Dry heat test at + 85C: 10 days, IEC 60512-6.

RELIABILITY
* RoHS Compliant, CE and FCC verified.
* Enclosure Protection Level: IP54.
With a special filter in the fans, it can be protected from the dirt and water spray from all the directions.
* Touchscreen Vandal resistant:
With a tempered, 4mm-thickness-glass, these touchscreens can withstand the impact of a 500g steel ball, dropped from a height of 1.3 meters, in accordance

With Trial Standard Number 60950C IEC 1999
* Lifespan >3 years.
* MTBF >50000H.
* MTTR <120min

KMY kiosk hardware solution
Components	Specification
Computer	Industrial PC or Standard PC upon request Support variable processors, Supports Intel Core™ i7/i5/i3 processor, Intel Core 2 Duo, Intel Pentium Dual-Core, Intel Pentium 4, Intel ATOM series, Intel Celeron, etc.  Min 2G RAM, Min 250HDD, or SDD flexible. Supports serial ports and USB ports for satisfying different devices connection Industrial Power supply; Graphics integrated Wireless or Ethernet collection available.
Monitor	A+ class TFT-LCD Monitor: 15, 17 , 19, 21, 22, or bigger size or smaller size available.
Touch screen	SAW touch /Infrared touch / Capacitive touch//5 wire resistive touch against different kiosk project requirements.
Bill acceptor	Accept single banknote or bulk banknotes of different countries
Card reader	Read & Write  IC/Magnetic/RFID cards
Printer	Thermal Printer : Width 58mm~210mm; black mark sensor; full/half cutter
Speaker	Multimedia : Left-right bi-channel amplified output
Enclosure	Moisture proof, Antirust, Anti-acid, Anti-dust, Static free High quality steel sheet made enclosure/ stainless steel / Aluminum available. Powder coated finish; color to be negotiated with customer;  with various customized buttons.
OS& Drivers	Windows XP/Window7/Unix/Linux OS available; All related hardware drivers/SDK available for the software development/integration
Packing	Bubble Foam, carton, wooden case
Other Optional : UPS, Video Camera, Alarm System, Barcode Scanner, Metal Keyboard, Photo Printer, Cash Acceptor, Check Acceptor, Infrared, Bluetooth, PSAM Card, etc.
