FZ-PCB company profile:
Specialize in prototypes to large batch production
High technology 1~20 layers pcbs from 0.2~3.2mm thickness with 0.3~6.0oz copper thickness, conform to rohs/ul, ISO9001: 2008 & ISO/TS16949: 2009, ISO14001: 2004
Fr4, fr4(tg130, 150, 170), fr1, cem-1, cem3, aluminum based, hf (rogers, teflon)
Hdi and sequential lamination
Flexible, flex-rigid and rigid pcbs
Turnover usd$60 million (2012-2013)
Established in 2002
Privately owned company
32000 square meter facility
Nearly 1000 employees
62500 square meter monthly output
What will you get from fz-pcb:
Reliable and stable quality with more than 12 years pcb manufacturing experience.
Quick response & 24 hours available service.
Professional sales service & advice.
Fulfillment of our promises, no lies.
Protecting your intellectual property. All our staff of trained professionals are working under a strict confidential contract.
Testing Procedures For PCB Board:
We perform multiple quality assuring procedures before shipping out any PCB board. These include:
* Visual Inspection
* Flying probe
* Impedance control
* Solder-ability detection
* Digital metallograghic microscope
* AOI (Automated Optical Inspection)
How to get a quote?
Pls send gerber file with these formats: . PCB /. P-CAD /. DXP /. CAD /. Gerber
A) Base material: FR4/ AL/ FPC/ CEM-1/ CEM-3/ 94v0/ Rogers
B) Board thickness: 1.6mm-3.2mm/ 0.3mm-1.2mm
C) Copper thickness: Hoz/ 1oz/ 2oz/ 3oz/ 4oz, ect
D) Surface treatment: HASL/ ENIG/ LF-HAL/ Immersion Tin/ Immersion Sin/ OSP
E) color of solder mask and silkscreen: Green/White/Black/Red/Blue/Yellow
F) Quantity and board size
Package and shipping method:
1. Vacuum package with silica gel, carton box with packing belt.
2. By dhl, ups, fedex, tnt
3. By ems (usually for russia clients)
4. By sea for mass quantity according to customer's requirement
Payment method
1. T/T
2. Paypal
3. Western union
|
Files |
Gerber, Protel, Powerpcb, Autocad, Orcad, etc |
|
Material |
FR-4, Hi-Tg FR-4, Lead free Materials (RoHS Compliant) , FR1, CEM-3, CEM-1, Aluminium, High frequency Material (Rogers, Teflon, Taconic), Polymide. |
|
Layer No. |
1 - 16 Layers |
|
Board thickness |
0.0075"(0.2mm)-0.125"(3.2mm) |
|
Board Thickness Tolerance |
±10% |
|
Copper thickness |
0.3OZ - 6OZ |
|
Impedance Control |
±10% |
|
Warp and Twist |
≤0.075% |
|
Peel Strength |
≥61B/in(≥107g/mm) |
|
Min Trace Width (a) |
3mil |
|
Min Space Width (b) |
3mil |
|
Min Annular Ring |
0.004"(0.1mm) |
|
SMD Pitch (a) |
0.012"(0.3mm) |
|
pcb with green solder mask and LF-FREE surface finishing BGA Pitch (b) |
0.027"(0.675mm) |
|
Register tolerance |
0.05mm |
|
Min Solder Mask Dam (a) |
0.005"(0.125mm) |
|
Solder mask Clearance (b) |
0.005"(0.125mm) |
|
Min SMT Pad spacing (c) |
0.004"(0.1mm) |
|
Solder Mask Thickness |
0.0007"(0.018mm) |
|
Hole size |
0.008"(0.20mm)-- 0.257"(6.5mm) |
|
Hole Size Tol (+/-) |
±0.003"(±0.0762mm) |
|
Max PTH Aspect Ratio |
10:1 |
|
Hole Registration |
0.003"(0.075mm) |
|
HASL |
2.5um |
|
Lead free HASL |
2.5um |
|
Immersion Gold |
Nickel 3-7um Au:1-3u'' |
|
OSP |
0.2-0.5um |
|
Panel Outline Tol (+/-) |
±0.004''(±0.1mm) |
|
Beveling |
30°45° |
|
V-cut |
15° 30° 45° 60° |
|
Surface finish |
HAL, HASL Lead Free, Immersion gold, Gold plating, Gold finger, immersion silver, immersion Tin, OSP, Carbon ink, |
|
Certificate |
ROHS ISO9001 TS16949 SGS UL |
|
Special requirements |
Buried&blind vias, Impedance control, via plug, BGA soldering and gold finger |
FZ-PCB is one of Asia' S leading full-service PCB to PCBA solution providers. Established in the year 2002, mainly provide the high-level quality PCB board and PCB assembly service to our customer which are the leading companies in the telecommunication, LED, medical treatment, aviation, instrumentation, micro-electronics and automated-control area. Our achievements are recognized through our customers' Success, industry and customer recognition, and continuous quality improvement.
