Product Name:Full Automatic Sleeve Shrinking Packaging Machinery (YCTD-YCBS60)
Category:Single Roller Film Wrapping Machine
CHARACTER:
Specially designed for bundle packing of beer,drinks and beverage,fruit juice,bottle water,dairy,condiment and so on with or without bottom support.
Unique film layoff mechanism and constant tension film conveyor are adopted,featuring instantaneous film cutting,automatic film connecting and wrapping higher strength after shrinking packing.
Equipped with B&R servo motor control system,bottle-feeding,film feeding,film cutting and film wrapping are accurate,synchronous,stable and reliable.
The LCD touch-screen has a friendly operation interface,and it is rapid for parameter setting and convenient for human-machine communication,operation and control.
Shrink tunnel uses unique air circulation configuration, transfer belt runs smooth,wearable and with longer service life.
Use air circulation technology,the shrinkage chamber features unique structure,heat insulation,high precision for temperature control and better packing effects.
The ideal model of middle-speed heat-shrinking packager in the domestic market.National Patent Technology.
SPECIFICATION:
Dimension For The Whole Unit | L19605mm×1530mm×2500mm |
| Thermal Shrinkage Tunnel Dimension | L2500mm×700mm×450mm |
| Max Package Dimension | L460mm×W280mm×H350mm |
| Packaging Speed | 55Pcs/minute |
| Transfer Belt Dimension | 610mm |
| Work Voltage/Power | 3Phase 5Line 380V/50Hz 60KW |
| Work Air Pressure | 0.6-0.8Mpa |
| Air Consumption | 100NL/min |
Beijing Y. C. T. D. Packaging Machinery Co., Ltd. is a high-tech enterprise which focuses on drinks secondary packaging line; Founded in 2001, the registered trademark "YCTD. " The company headquarters is located in Beijing Daxing Yufa industrial zone, near the Da-Guang high-speed, Lang-zhuo high-speed; And it is adjacent to the capital second airport, convenient transportation.
We are one of the biggest Shrink Packing Machine/Carton Wrapping Machine/Pallletizer solution providers, which has complete ability of technology development, product design, manufacturing, service of pre-sales and after. The company has more than 200 staff, professional and technical staff of nearly 50 people.
It has passed ISO9001: 2000 international quality management system certification, European CE certified national safety standards. And has 20 national patents packaging machines. As a member of China Packaging Federation, China Light Industry Federation governing units, the China Beverage Industry Association, China Brewing Industry Association, We are the members of China Packaging Federation, and for 3 consecutive years as Beijing trustworthy company. Product market share is ahead.
The products are widely used in beer, beverage, pure water, mineral water, fruit juice, dairy product and condiment, etc. Already have become Huiyuan Group, Coca-Cola, Dali Group, United Group, Master Kong, Harbin Pharmaceutical Group, Tsingtao Beer, Wong Lo Kat and other well-known brands trusted partner of packaging equipment; Shrink packing machine, carton wrapping machine, palletizer and other turn-key project products have been exported to more than 60 countries and regions in North America, South America, Africa, Europe, the Middle East and so on.
We successfully cooperate with many famous enterprises, which received widely trust from the users with found industry experience, which is a true famous brand in the industry of thermal shrink packing with strong competition.
March 2014 the company name voted to build a new base in Handan 200 acres, is expected to formally put into use in 2015; So far, our company has two research and development, manufacturing plants, covers an area of over 150, 000 square meters, the new plant will become the second largest drinks packaging machinery R & D and manufacturing base in China, not only can achieve large-scale production, reduce costs and shorten delivery time; Equipped with better after sales service team, which allows the company to provide our clients with better products, more efficient services and have more reliable protection.
YCTD--Chinese drinks secondary packaging professional solution provider!
YCTD--Innovative packaging for you, win products new profits!
