Apply to abdomen, GYN, obstetric, pediatric, urological, cardio and small parts, etc
15'' LCD display
Probe Mode: Electronic convex, electronic linear
Probe element: 128 elements
Standard probe: 3.5MHz convex multi-frequency probe
(Frequency conversion scope: 2.0 / 2.5 / 3.5 / 5.0 MHz)
Optional probe: 6.5MHz intra-vaginal frequency conversion probe.
(frequency conversion scope: 4.0 / 5.0 / 6.5 / 7.5 MHz)
7.5MHz frequency conversion probe.
(frequency conversion scope: 5.0 / 6.5 / 7.5 / 9.0 MHz)
5.0MHz micro-convex frequency conversion probe.
(frequency conversion scope: 3.5 / 4.5 / 5.0 / 5.5 MHz)
3.5MHz cardiology multi-frequency probe
(Frequency conversion scope: 2.0 / 2.5 / 3.5 / 5.0 MHz)
Scanning angle: Convex probe 60° , intra-vaginal probe 130°
64 kinds body mark with probe direction
Probe socket: 2 sockets, automatically identify the probe
Physical receiving channel: ≥ 32 channels beam former
Scan mode: B, 2B, 4B, B/M, M
Full view image 28 ranges depth adjustment
Gain range: Total gain continuous adjustment(0~127dB)
Dynamic range: 27~100dB, visible and adjustable
Four changeable angles/width
Gray scale: 256
Image technology: Full digital beam former technology, continuous dynamic focus, dynamic aperture
Image storage: C: / dick in host is 32MB, can save 100 images permanently even if electronic power is turned off.
Cine loop: 256
TGC adjustment: 8 stages
Image processing: Pre-process (continuous dynamic focus, dynamic aperture, dynamic filter), post-process(4 grades gamma correction), frame correlation, black/white reversal, left/right reversal, up/down reversal, edge enhancement, etc.
Image depth enhancement and local zoom function
Measurement and analyze function
General measurement: Distance, circumference, area, volume, slope, heart rate and cycle.
Obstetric measurement and analyze: BPD, CRL, GS, FL, HL, TAD, TBD, APBD, HC, AC, GA, EFW, FT, LV, THD, TCD, OFD, AFI, LMP, fetal growth curve(dingle frame, four frames), OB report;
Cardio measurement and analysis: M routine measurement software package (depth, slope, heart rate, cycle), cardio measurement software package (left ventricle function, mitral valve, aorta, ejection period, cardiac muscle weight, cardio report.
Gyn. Measurement and analysis: Uterus volume, endometrium thickness, ovary volume, superior ovarian follicle, uterine neck long dia, GYN report, etc.
Urological measurement and analysis: Residual urine, volume of prostate, Urological report
Report: OB report, fetus growth curve, cardio report, Gyn report, Urological report
Note: Name, age, gender, hospital name, time, date, probe type, frequency, focus, frame correlation, gain, dynamic scope, etc.
Backlight silica gel keyboard and photoelectricity track ball
Puncture guide, with two approvable guiding lines whose angle and position can be adjustable.
USB-A socket for flash disk to store images directly (it can store both patient image and relative report. Support file management, disk management and software update. )
USB-B socket for transferring of the real time image (optional software of case report process center)
DICOM 3.0
Output: PAL / NTSC
Power supply: 110/230V± 10%, 60/50MHz ± 2%
Energy-saving
8 kinds internal pseudo color, 10'color LCD and bracket can be selected as optional parts
Print output: Video printer(optional parts), optional software of case report process center(work station). Appointed laser printer includes HP Laser Jet 1020, HP Laser Jet 1022, HP Laser Jet P1007, HP Laser Jet P1008 can be connected to print the image & report.
