Price: | US $ 121/Piece |
---|---|
Trade Terms: | FOB |
Min Order: | 10/Piece |
Pay Type: | T/T,Paypal,Money Gram,Western Union |
Prod Model: | TC-135 |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Frequenvy Range: | 136-174MHz |
Output Power: | 10W/25W/60W |
1750Hz Tone: | Support |
Ctcss/Dcs Setting & Scanning: | Support |
0-9 Sql Grade Setting: | Support |
Voice Compander: | Support |
Dtmf/2 Tone/5 Tone: | Support |
Emergenvy Alarm: | Support |
Busy Channel Lock-out: | Support |
Certification: | CE |
Application: | Military |
Wavelength And Frequency: | Middle-wave |
Style: | Ground Wave |
Condition: | New |
Screen: | With Screen |
Standard: | Standard |
Frequency Range: VHF:136-174MHz UHF: 400-490MHz | |
Output Power: VHF: 10W/25W/60W UHF: 45W/25W/10W | |
1750Hz Tone | CTCSS/DCS setting & scanning |
0-9 SQL grade setting | Frequency/Channel scanning |
High/Mid/Low power selectable | Voice compander |
Repeater offset shift | Keypad lock function |
Contact book | Battery voltage display |
DTMF/2 tone/5 tone | ANI ID |
Remote kill/ stun/ activate/ revive | Emergenvy alarm |
Wide/Narrow band setting | TX inhibit |
Busy Channel Lock-Out | Channel name editing |
Reverse frequency | Talk around |
Scrambler(Optional) | Voice prompt |
Time-out Timer | Auto Power off |
VFO step setting:5/6.25/10/12.5/20/25/50kHz |
Model | TC-135 |
General | |
Frequenvy Range | 136-174/245-246/400-490MHz |
Channel Capacity | 200 |
Channel Spacing | 5/6.25/8.33/10/12.5/15/20/25/30/50KHz |
Freruency Stability | 2.5ppm |
Operating Temperature | -20°C ~ + 60°C |
Operating Voltage | 13.8V DC ± 15% |
Dimension(HxWxD) | 145mm x190mm x47mm |
Weight(with bracket) | 1200g |
Receiver | |
Reference Sensitivity | 0.25V / 0.35V |
Operating Bandwidth | 60dB 12.5KHz /70dB 25KHz |
Adjacent Channel Selectivity | 60dB 12.5KHz 70dB 25KHz |
Inter-modulation Rejection | ≥60dB/ ≥65dB |
Spurious Response Rejection | ≥70dB |
Rated Audio Response | +1-+3dB |
Rated Audio Distortion | <5% |
FM Hum&Noise | ≥40dB 25KHz /≥45KHz 12.5KHz |
Transmitter | |
RF Power | 45W/25W/10W(UHF)/60W/25W/10W(VHF) |
Frequency Modulation | 11kΦF3E / 16kΦF3E |
Modulation Distortion | <5% |
FM Noise | ≥36dB 25KHz /≥40KHz 12.5KHz |
Adjacent Channel Power | ≥60dB 12.5KHz /≥70KHz 25KHz |
Audio Response | +1-+3dB |
Audio Distortion | <5% |
