Product Specifications
| Prod Model: |
DEK-GABION |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Wire Diameter: |
2.0-4.0mm |
| Aperture: |
60*80-120*150mm |
| Inspection: |
SGS.BV |
| Certificate: |
ISO9001:2008 |
| Feature: |
Firm, Durable |
| Hole Shape: |
Hexagonal |
| Application: |
Gabion Mesh |
| Material: |
Low-Carbon Iron Wire |
| Surface Treatment: |
PVC Coated |
Product Description
Material
Low Carbon Steel, Electric Galvanized Gabion Mesh, Hot Dipped Galvanized Gabion Mesh, PVC Coated Gabion Box
Surface treatment
Hot dipped Galvanized
Galvanized + PVC coated
Advantages
1. Flexible
Superior to rigid type structures. The hexagonal mesh construction permits natural adjustment to varying conditions of earth settlement without causing fracture or collapse of the structure.
2. Durable
Gaps between the stones silt up naturally as time passes. Silting supports the growth of grass and plants which serve as a bonding agent for the stone.
3. Permeable
A Gabion structure allows water to pass through, water pressure cannot build up behind it and the structure is continuously drained.
4. Strong
The flexibility of the Gabion structure provides the inherent strength to withstand and dissipate pressures exerted by water and earth masses.
5. Economical
Filling materials are usually found on or near the site. No structural maintenance is needed and foundation work is usually unnecessary.
6. Natural Appearance
Natural stone makes the structure aesthetically pleasing especially when subsequent vegetation growth takes place.
7. Simple
Unskilled labor can be used for quick assembly.
8. Maintenance
Gabion structures are easily maintained using additional mesh or grouting.
9. Function
Once the structure is built there is no waiting period it functions immediately.
10. Extendable
Extensions are simple. Additional units are simply attached to the existing ones
Main uses
1. Controlling and leading the river and flood.
2. Flood discharge and lead flow.
3. Rock fall defending.
4. Preventing the water and soil lost.
5. Protecting the bridge.
6. Reinforce fabric.
7. Seashore recovery project.
8. Seaport project.
Installation Process
1. Unpack.
2. Pull out and set up.
3. Connect together.
4. Fill and compact.
Opening
(mm) |
Wire Diameter(Metal Wire) (mm) |
Wire Diameter (PVC Coate)/ Inner/Outside(mm) |
60X80 |
Ø2.0-2.8 |
Ø2.0/3.0-2.5/3.5 |
80X100 |
Ø2.0-3.2 |
Ø2.0/3.0-2.8/3.8 |
80X120 |
Ø2.0-3.2 |
Ø2.0/3.0-2.8/3.8 |
100X120 |
Ø2.0-3.4 |
Ø2.0/3.0-2.8/3.8 |
100X150 |
Ø2.0-3.4 |
Ø2.0/3.0-2.8/3.8 |
120X150 |
Ø2.0-4.0 |
Ø2.0/3.0-3.0/4.0 |
We Xi'an Dek Fence Co., Ltd. was established in 2002,
Our company is a professional large-scale manufacturer of all types of metal wire mesh fence, integrating development and production together.
Main products:
1. Welded wire mesh fence panel / Double welded arch fence / Chain link fence / Euro fence
2. Welded wire mesh roll / Hexagonal wire mesh (Gabion)
3. Temporary fence / Crowd control barrier / Traffic barrier
4. Reinforce mesh / Steel picket fence
Our aim is not only to provide products, but also provide a complete solutions.
Our products have been sold to 5 continents, over 30 countries including Poland, France, Australia, Mexico, Columbia and some countries in southeast Asia, etc. We attained ISO9001: 2008 certification.
Our company regards "Reasonable prices, Efficient production time and Good after-sales service" as our tenet. We hope to cooperate with more customers abroad on the basis of the mutual benefit. Welcome to contact us and visit our factory any time.
