Product Specifications
| Prod Model: |
FD6396 |
| Markets: |
South America,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia |
| Fuel: |
Gas/Petrol |
| Type: |
SUV |
Product Description
Model: FD6396 (1.6)
Specification:
Engine model: MITSUBISHI 4G18S
Transmission model: F5M41
Total mass (kg): 1505
Kerb mass (kg): 1180
Overall length (mm): 3850
Overall width (mm): 1785
Overall height (mm): 1665
Wheelbase (mm): 2280
Tread front/rear)(mm): 1525 /1520
Approach angle/departure angle (o): 31/40
Displacement L: 1.584
Fuel delivery: Multi-port injection
Max. Power (kw/r/min): 74.2 /6000
Max. Torque (N. M/r/min): 134/4500
Max. Speed km/h: 155
Max. Climbing capability: 40
Fuel consumption per hundred kilometer (L/100km): 6(fuel consumption in limitative condition)
Fuel tank capacity: 57L
Research octane number RON: 93
Air-conditioner kw: 5.23
Displacement standard: GB18352.3 \Euro 4
Rated passenger: 4
Transmission system: 5-speed manual
Steering system: Hydraulic with power assist
Brake system: Four-wheel disc
Mini. Ground clearance(mm): 180
Mini. Steering radius M: 5
Suspension system front rear: Macpherson struts/multi-connecting rod
Tire: 215/65R16
Body structure: Unitary construction.
Zhejiang Jonway Automobile Co., Ltd is the subsidiary of Jonway Group. Jonway Group manufactures automobiles, motorcycles, vehicle and motor parts, light building materials, air-compressors, plastics as well as other vehicle subcomponents. In 2009 Jonway Automobile had sales of more than US$110 million.
Zhejiang Jonway Automobile Co., Ltd began manufacturing in May, 2003. Located at the beautiful East China sea coast-port industry zone of Jiangtiao, Sanmen county. The Taizhou city, Zhejiang province manufacturing plant has an area of 57.3 hectares with more than 800 employees. It has invested more than 600 million RMB in producing the three- and five-door SUVs, with a capacity to produce up to 30, 000 units per year. The manufacturing operations include pressing, welding, painting and assembling lines. It has also gained the TS16949: 2009, GCC, SASO, SONCAP and CCC certification. Jonway offers a network of more than 500 auto dealerships in China alone and has started a distribution network in Italy.
