New Model Vertical CNC Machine Tool (KDVL460L)

Name: New Model Vertical CNC Machine Tool (KDVL460L)
Brand: china-manufacturer-directory.com
SKU: 774690025
Availability: InStock
Rating: 4.9 (132 reviews)

Price:	US $ 50000-100000SET
Trade Terms:	FOB,CFR,CIF
Min Order:	1SET
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

PRODUCT FEATURES:
Compact structure, ridgid spindle component and good for heavy cutting.
Easy to chuck and remove, Workpiece roundness and other precision are ensured.
The turret on the slide moves along longitudinal or cross rails. There are three cross rails to support the slide. Ball screws and linear rails are used to ensure smooth feed and ghgn precision.
Different handles, electric buttons and CRT displayer are all on the same rocking panel for easy operation>
Machine totally sealed guard structure. Back side chip removal conveyor.

ITEMS		KDVL460 KDVL460L	KDVL600
Capacity	Max. swing	Φ 530 mm	Φ 650mm
	Max. cutting diameter	Φ 500mm	Φ 600mm
	Max. height or turning	430mm	600mm
Spindle	Spindle nose	A2-8	A2-8
	Front spindle bearing ID	Φ 120mm	Φ 140mm
	Spindle speed range	100-2000r/min	100-2000r/min
	Steps of spindle speed	Varlable	Varlable
	Chuck dia.	12"	18"
Travel	Travel of X axis	-50; +250mm	-30; +300mm
Travel	Travel of Z axis	450mm	600mm
Feel	Rapid feed of X axis	8m /min	10m /min
Feel	Rapid feed of Z axis	10m /min	12m /min
Tool Post	Type of tool stations	Hydraulic	Hydraulic
	Number of tool statins	8	8
	Tool shank size(square)	25X25mm	25X25mm
	Tool shank size(round)	Φ 40mm	Φ 40mm
Motor	Main motor	15 18/5KW	18.5/22KW 11KW
	Hydraulic pump motor	1.5KW	1.5KW
	Coolant pump motor	200W	370W
Other	Overall dimensiln(LxWxG)	1590X2670X2545mm	23650X2700X3200mm
Other	Net weight	4500Kg	8000Kg

Prod Model:	(KDVL460L)
Markets:	North America,South America,Eastern Europe,Southeast Asia,Mid East,Eastern Asia,Western Europe
Max Swing:	530mm
Max Cutting Dia:	500mm
Spindle Nose:	A2-8
Type:	Vertical Lathe
Processing Accessory:	Centre CNC Lathe
Tool Holder:	Single-tool Holder CNC Lathe
Power Source:	Electric
Controlling Mode:	CNC
Automatic Grade:	Automatic
Setting Mode:	Floor-type
Precision:	High Precision

Zhejiang Kaida Machine Tool Co., Ltd

Zhejiang Kaida Machine Tool Co., Ltd is located in Zhuji City, China.And only 45 minutes away from Hangzhou Airport.

Our company was founded in 1952 and has a history of more than 60 years in manufacturing lathes, also with a total area of 32 hectares and 1000 staff.Through reformation in 1997, we have been changed from a state-owned enterprise to a joint-stock private enterprise.We got ISO9001 certificate in 1997, CE certificate in1999 and ISO14001 certificate in 2005.

We have a wide variety of products, which can meet different customers' needs:Horizontal machining center, vertical machining center, CNC slant bed lathe, CNC flat bed lathe, manual lathe.

We have a full set of equipment including forging, machining, heat-treating, sheet metal processing, assembling and painting.Specialized technicists in every field enable us to assist our customer in use, learning and programming.Efficient service earn us trust and loyalty from customer.

As an established company, professional competence and perfect service make us to exploit and develop a huge international marketing net.Our export experience started from European and America.We have exported to more than 100 countries.Our main markets are Europe, America, South America, India, Southeast Asia, South Africa.

We are fully confident to meet any challenges or opportunities that present to us.
