PLC Controlled PE Coated Paper Cup Machinery (MB-12/22)
PLC controlled pe coated paper cup machinery features:
1. Bottom sealing by hot air devices, which is import from switzerland, LEISTER BRAND, high efficiency and durable.
2. And cup side sealing by ultrasonic, Evergreen which is made in Taiwan; (If you will not change mould, only one mould work with the machine. )
3. More efficient and better performance. The speed could be 60-80 pcs/min
4. Cup top curling and bottom knurling are finished by two separate turning plates.
5. It is easy to make cups with different sizes by changing moulds.
6. Have an automatic cup delivery system and stacking system with auto counter.
7. Equipped with automatic bottom paper roll lifting system, it is very easy to change the bottom paper roll, labor saving.
8. All the electrical parts are Schneider and Siemens brand, best configuration, which insure the long life span the machine
9. Automatic lubricating system, no need to doing the daily maintenance, and much easier for the operator.
10. Bottom paper will cut off and transfered by the transfering tape to the garbage automatically.
PLC controlled pe coated paper cup machinery technicial Data:
1. Cup Category: Round paper cups, hot beverage drinking cups, noodle cups and vending cups ice-cream and food containers and also square cups for biscuits, cookies and chips.
2. Cup Size: 6oz ~32oz (100cc ~ 700cc) Raw material: 190~~500 gsm Single or Double PE coated paper
3. Output: 60 ~ 80 cups per min.
4. Maximum cup dimensions
-max. Top diameter: 115mm
-max. Cup height: 170mm
-max bottom diameter: 80mm
5. Minimum cup dimensions
- min. Top diameter: 55mm
- min. Cup height: 60mm
- min. Bottom diameter: 45mm
6. Electrical requirement: 380V, 50Hz, 3 phase or 220V 1 phase
7. Electric consumption: Max 13.0Kw
8. Air consumption: Approx 0.4 m³ /min
9. Machine dimensions: 2.8m× 1.6m× 1.6m
10. Machine Weight: 2, 300kg
PLC controlled pe coated paper cup machinery working video, please refer to the following online website link:
http://v.youku.com/v_show/id_XNjI3NjUzMzg0.html
About mingbo machinery:
Mingbo machinery is one of the leading manufacturer of paper cup machine, paper bowl machine, paper plate machine die cutting machine and also the cup lid machine as well as the burger box machine. Its high quality machinery leads customer to create more profit and trouble free.
Our machine quality is guaranteed for one year.
We will offer spare parts for you which is enough for one year running.
And we can also send the technician to customer's factory to help installation at the cost of buyer.
And other than the above, we also supply the 24 hours online service.
We will offer the most professional suggestion to help you start and expand your business!
We assure you of our best service at all times.
ZB-12/22 technical data: |
Cup Size |
6oz ~32oz (100cc ~ 700cc) |
Raw material |
190~~500 gsm Single or Double PE coated paper |
Output |
60 ~ 80 cups per min |
Maximum cup dimensions |
|
max. top diameter |
115mm |
max. cup height |
170mm |
max bottom diameter: |
80mm |
Minimum cup dimensions |
|
min. top diameter |
55mm |
min. cup height |
60mm |
min. bottom diameter |
45mm |
Electrical requirement |
380V, 50Hz, 3 phase or 220V 1 phase |
Electric consumption |
max 13.0Kw |
Air consumption: |
approx 0.4 m³/min |
Machine dimensions |
2.8m×1.6m×1.6m |
Machine Weight |
2,300kg |
Mingbo Machinery leads the world with innovative technology in designing and manufacturing paper cup and paperboard container forming machines, paper cutting machine, flexographic printing machine, and die cutting machine and so on. Mingbo Machinery builds its technology on experience and research, for that reason we can supply various equipments with best quality.
Our equipments have sold well on more than 30 domestic cities and broad, such as southeast, the southeast Asia, the Middle East, Romania, Australia, Africa and other countries and regions.
welcome to join in Mingbo, and lets step into mutual success!
