Rubber grinding machine tool MJ6193-4500MM
Swing over bed 930mm
Swing in gap 1100mm
Swing over cross slide 650mm
Max. Turning Diameter: 650mm
Max. Grinding size: 400mm
Distance between centers 4500mm
Max. Grinding length: 3900mm
Max. Turning length: 4300mm
Spindle bore 105mm /130mm optional
Model of grinding head: FY300/FY400/FY500
Spindle speeds 10-800rmp / 18steps
Cross slide travel 480mm
Top rest travel 225mm
Quill taper MT5
Bed width 550mm
Main motor power 11KW
Main specification | Unit | Model |
| MJ6193 |
Max. Swing over bed | mm | 930 |
Max. Swing over saddle | mm | 650 |
Max. Grinding size | mm | 400 |
Max. Turning Diameter | mm | 650 |
Distance between centers | mm | 4500 |
Max. Grinding length | mm | 3900 |
Max. Turning length | mm | 4300 |
Model of grinding head |
| FY400 |
Rotary speed of grinding head | r/m | 1672 |
Size of grinding wheel | mm | 400*127*40(metal)/350*127*40(PU) |
| Motor power of grinding head | kw | 4 |
Linear velocity of grinding wheel | m/s | 35(metal)/ 28(PU) |
Dia. Of tailstock | mm | 90 |
Taper of tailstock |
| MT5 |
Bed width | mm | 550 |
Main motor power | kw | 11 |
Changsha Jinling Machine Tool Co., Ltd., reconstructured from the state-owned medium firm - Changsha No. 2 Machine Tool Plant - an lathe production plant designated by the former Machinery Ministry with 50 years of experience in machine tool production, is a private joint-stock high-tech enterprise approved by the Changsha People's Government in 2004. Located in No. 628, Lugu Avenue, Hexi, Changsha, Hunan, the company covers an area of 100 mu, the plant area of 30, 000 square meters with more than 500 various types of machining and inspection equipment. With total assets of over RMB 100 million, the company has a wholly owned subsidiary (Changsha Jinze Machinery Co., Ltd. ) and a holding company (Changsha Jinling CNC Grinder Co., Ltd. ).
Our main products are "Jinling"XK series CNC milling machines, XH series vertical machining centers, CKA, CKB, CKC, CKD Series CNC lathes, CW, CJ, CX, CS series horizontal lathes, GMKF series high-speed CNC profiling grinders, CK series CNC slant bed lathes, and JL series CNC piston lathes and others. Products not only are sold in the domestic markets, but also exported to more than 40 countries and regions such as the United States, Germany, Italy, South Africa, Indonesia, Pakistan, Vietnam, and Saudi Arabia. In 2002, the company passed the certification of ISO9001: 2000 Quality Managment System. In 2008, CW series obtained "CE" certification. Jinling products, thanks to excellent performance, high quality, and superior after-sales services, has been well-acclaimed by customers at home and abroad. In 2008, "Jinling" won the title of "Hunan Famous Brand".
