SSR-DD Single phase DC Solid state relay
Main Feature:
1. Rated voltage output: 40~240VAC, 60~440VAC
2. Rated current output: 10,15,20,25,30,40,50,60,70,80,100,120A
3. On-state voltage drop: ≤1.8V
4. On-off time: ≤ 10ms
5. Current leakage in Disconnection: ≤10ms
6. Input voltage: 3~14VDC, 3~32VDC, 90~250VAC
7. Input current: 6~35mA
8. Isolating voltage: ≥1500VACA
9. Ambient temperature: - 25~70 °C
10. Working indication: LED11. Remark: Heat sink must be installedWhen the load reaches to10A or above.Specification
Specifications/Dimensions |
|
L x W x H | 57.5x44.8x31.5 |
Electrical Specifications |
|
Controlling Voltage | 3-32VDC |
Controlling Current | 6-35mA |
Make-on Voltage | 3.5VDC |
Break-off Voltage | 1.5VDC |
Reverse Voltage | 32VDC |
Load Voltage | 24-480VAC |
Load Current | 10,25,40,60,80,100,120A |
Instant Voltage | 900VAC |
Voltage Dropin On | <1.5V |
On-off Time | ≤10ms |
Leakage Curent in off | ≤10mA |
Dielectric Strength | ≥2500VAC |
Insulation Resistance | 500MΩ500VDC |
Ambient Temperature | -30~80ºC |
Indicate Methods | LED |
PS:If you can't find the exact type of your product.Please don't rush to go away.Contact me and your questions will be replied ASAP.Thank you for your time.
