Product Specifications
| Prod Model: |
HQ908 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Engine: |
Perkins |
| Operating Weight: |
1650kg |
| Turnin Angle: |
43 Degree |
| Bucket: |
0.4m3 |
| Type: |
Small Loader |
| Walking Mode: |
Wheeled |
| Load And Unload Method: |
Front Discharge |
| Certification: |
SGS,Rops&Fops |
| Condition: |
New |
| Scraper Type: |
Front End Shovel |
| Engine Power: |
18.5kw |
| Color: |
According to Customers Requirments |
Product Description
Excellent performance
1,Original Perkins Engine
2, The closed hydrostatic system has the feature of lower energy consumption.
3, Simple quick-change construction can meet multipurpose operation of users.
4, The integrated multi-functional control handle makes operation simple.
5, The monitor has the LED showing of fuel level by stages.
6, The unique frame hinge type is compacted and durable.
7, The widely applied broad-face tyre and damping seat is safe and comfortable.
8, Small working radius, mobile and flexible.
| Engine |
|
| Model | Pekins 403D-11 |
| Rated power | 18.5kw(24.8BHP) |
| Rated speed | 2800rpm |
| Maximum torque | 67Nm |
| The ratio of fuel consumption | 252g/kwhr |
| Dimensions |
|
| Body length | 3690mm |
| Body width(reverse tyre) | 1050mm/970mm |
| Body height | 2300mm |
| Minimum ground clearance | 200mm |
| Maximum dumping height | 2000mm |
| Dumping reach | 600mm |
| Wheel base | 1340mm |
| Performance parameters of the machine |
| Bucket | 0.4m3 |
| Tipping load in shovel, vehicle straight raight straight798kg | 800kg |
| Tipping load in shovel, vehicle at 43° | 580kg |
| Operating weight | 1650kg |
| The sum of the work device | 8s |
| Driving speed | 0-12km/h |
| Minimum turning-circle radius |
|
| Outside face of bucket | 1989mm |
| Outside face of tyre | 1469mm |
| Tyre specifications | 27*8.5-15TL |
| Maximum turning angle | ±68° |
Since 2002, Weifang HainQin Machinery started to work hard and manufacture every kinds of good quality wheel loaders, backhoe loaders, wheel dumpers etc for our customers. Our wheel loaders got CE certificate, ROPS & FOPS Certificate, with E4 standard glass, USA steering system etc. Now our loaders exported to more than 30 countries, and gained high evaluation from our customers.
" Quality first " Is always the rule of Haiqin Machinery. From the parts purchase, production management, machine testing, delivery of shipment etc, all have professional and technical personnel to inspect. This will ensure that each machine of high quality!
" Quick after sales service" is also very important. We have professional technical personnel for technical service and spare parts warehouse for supplying spare parts service. Now we cooperated with DHL/FedEx, and can send the parts to the customers adress in 4 or 5 days!
"Technical research and innovation", We have to keep up with the pace of the international engineering machinery development. Every year, there are 40% of the total profit put into technical research and innovation. This will always enable us to keep the leading position in the construcion machinery field.
We hope to cooperate with the friends from all over the world and make mutual benefits!
