Product Specifications
| Prod Model: |
GCPR-G10 GCPR-D10 GCPR-W10 GCPR-C10 GCPR-P10 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Installation Type: |
Indoor, Small Size |
| Technic Advantage: |
Alc&Agc |
| Certificate: |
CE RoHS ISO |
| Type: |
Wireless Repeater |
| Transmission Medium: |
Cable |
| Standard: |
Standard |
| Lightning Protection: |
With Lightning Protection |
| Certification: |
CE |
| Condition: |
New |
Product Description
Features:
1.With Oscillation Detective Indicate Function;
2..With Uplink/Downlink auto gain synchronization, can adjust the UL/DL gain;
3.High gain, easy installation and operation.
4.Use ALC and AGC technology, adjust extent automatically.
5.LED Light Working & Signal Condition Indicators.
6.Dependability stand by GB6993-86 standard.
7.Compatibility of electromagnetism according with ETS300 609-4.
We can make such as frequenies:
For indoor single band intelligent repeater: GSM900, GSM1800, GSM1900M, CDMA850, 3G2100, IDEN, LTE etc
For dualband and tri-band intelligent repeater: GSM900+GSM1800 dualband, GSM900+3G2100M dualband, 900+1800+2100 triband etc.
Outdoor series: Fullband repeater, band selective repeater, frequency selective repeater, frequency shifting repeater etc.
Electrical specification | Uplink | Downlink |
| Frequency | CDMA800 & GSM850 | 824 ~ 849 MHz | 869 ~ 894 MHz |
| CDMA1900 | 1850 ~ 1910 MHz | 1930 ~ 1990 MHz |
| GSM900 | 890 ~ 915 MHz | 935 ~ 960 MHz |
| EGSM | 880 ~ 915 MHz | 925 ~ 960 MHz |
| DCS | 1710 ~ 1785 MHz | 1805 ~ 1880 MHz |
| PCS | 1850 ~ 1910 MHz | 1930 ~ 1990 MHz |
| WCDMA | 1920 ~ 1980 MHz | 2110 ~ 2170 MHz |
| Model Number | GCPR-G10 | GCPR-G15 |
| Output Power(Max) | 10dBm | 15dBm |
| Gain | ≥55dB | ≥55dB |
| Automatic Level Control | ≥20dB |
| Noise Figure | ≤5dB |
| Gain Flatness | ≤5dB (p-p), |
| Automatic Gain Control | 30dB in step of 1dB (Auto) |
| Input Power Range | ≤-25 dBm |
| IM3 | ≤-45dBc |
| Spurious Emission | 9KHz~150KHz | ≤-36dBm @ 1KHz |
| 150KHz~30MHz | ≤-36dBm @ 10KHz |
| 30MHz~1GHz (out of band) | ≤-36dBm @ 100KHz |
| 1GHz~6.7GHz | ≤-36dBm @ 1MHz |
| Group Delay | UL≤1μs |
| Operating voltage | AC 220V |
