Product Specifications
Prod Model: |
SUERPS10 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Weight: |
2.0kg |
USB: |
6* USB2.0 |
COM: |
2*RS232 |
Resolution: |
800(RGB)×600(SVGA) |
Working Environment: |
-30c_80c, 0-90 Ambient Humidity |
Hard Disk Capacity: |
32g |
Memory: |
2GB |
CPU Core: |
Dual-Core |
Operating System: |
Windows |
Type: |
IPC |
Screen Size: |
6-10'' |
CPU Type: |
Core Duo |
Power Supply Type: |
ATX12V |
Touch Screen: |
Touch Screen |
System Expansion Slot: |
7 Slot |
Hard Disk Rack Type: |
Board Type |
Installation: |
Wall-Mounted |
Application: |
Industrial |
Product Description
Product Description
Features
1. IP65 Waterproof Level High Luminance Led Panel (400 nits)
2. Intel® Atom™ D255 0 1.86GHz Processor
3. 10.1"XGA 800 x 600 Resolution Color TFT Led Display
4. Ultra Slim and Compact Mechanical Design
5. Supports Wide Range DC Power Input (9-30V)
6. Wireless 3G/WIFI/GPS Can Be Customize
Processor | CPU | Intel Atom D2550 1.86GHz |
Cache | 1MB L2 Cache |
Memory | 204 pin ddr3 800/1333 SODIMM Socket Onboard 2G(Supports 4GB) |
Graphics Card | GMA 3600 ,640MHZ |
Storage | Supports MSATA and Inner SATA2.5'' |
LAN | 2×(RJ-45),10/100/1000 Mbps |
I/O | Serial Ports | 2×RS-232,(Extensible 5xRS-232,Supports RS485 ,Can be Customized) |
USB Ports | Outer2×USB,Inner5×USB (extensible) |
I/0 | 1 x HDMI,1 x VGA |
Audio Interface | 1 x Mic,1 x Line-out |
| 1 x DC Port,1 x ON/OFF |
| 1 x Mini-PCIE,1 x Mini-SATA |
Weight | Net(kg) | 2.0 |
Gross(kg) | 2.5 |
| Overall Dimension(L×W×D) | 262×210×43 |
Installation Dimension(L×W) | 267.1×136.0 |
System | Windows XP,Windows XP Embedded,Win7,Win8,Linux ,etc |
Power Supply | | DC 9~30V |
LCD Display | Type | 10.1 Inch a-Si TFT-LCD |
Panel Type | M150XN07 v2 |
Max Resolution | 800(RGB)×600(SVGA) |
Display Color | 262K(6-bit) |
Contrast | 500:1(Typ.)(transmission) |
Visual Angel | 60/60/35/65(Typ.)(CR≥10)(L/R/U/D) |
Luminance | 400 cd/m2 (Typ.) |
Response Time | 10/25(Typ.)(Tr/Td)(ms) |
Pixel Pitch | 0.264×0.264mm |
Backlight | LED |
Touch Panel | Type | 4 Wire Resistive(AMT) |
| Resolution | Continuous |
| Optical Conduction | 80% |
| Controller | USB Ports |
| Durability | 35 Million Times |
Environmental Parameter | Working Temp | -40ºC~80ºC |
| Working Humidity | 10~95%RH@ 40ºC,Non-Condensing |
| Shock | 10 G (11ms,Non-Operating) |
| Vibration | 10 G |
| Certification | CE,FCC,ROHS |
Nanjing Super Lighting Technology CO. Ltd is a professional industrial tablet PC enterprise who engaged in tablet PC and PC parts. Our Company was founded in 1999, the mainstream products are 7inch industrial PC, 8inch industrial PC, 10inch industrial PC, 15inch industrial PC and so on. We have two Production base in Nanjing and Shenzhen and 20 offices nationwide.
There is a Professional technical team with strong researching ability and high development level in our work group. We have researched many kinds of products independently and got a number of national patents. We put customer' S needs first. Honesty is our core spirit. Good service and excellent product quality made us win many domestic customers' Praise. We formed a long-term cooperation relationship with TOP100 advertising companies in China. SUERPS spread all over China and many other countries in Africa and Southeast Asia.
" technical lighting, energy saving first" is SUERPS' S changeless purpose. We believe that a small daily improve will create a big clean earth. Come on, join in SUERPS. We will be your most loyal partners!
