Product Specifications
Prod Model: |
SC 185A |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Type: |
Screw |
Performance: |
Low Noise |
Drive Mode: |
Electric |
Power Source: |
AC Power |
Configuration: |
Stationary |
Material: |
Carbon Steel |
Piston Type: |
Closed |
Lubrication Style: |
Lubricated |
Application: |
Low Back Pressure Type |
Mute: |
Mute |
Product Description
475HP, water cooling, rotary screw compressor
Type: SC-355W
Specification:
-Model: SC355A/W, oil injected screw compressor
-Free air delivery: 60 m3/min, 2100 cfm
-Rated operating pressure: 7 bar
-Control type: Microprocessor PLC
-Main motor: 355KW, TEFC/IP54/1.15 S. F/1490 RPM
-Power supply: 380-415V/50Hz/3pH
-Rotor speed: 2500 RPM
-Driven type: Coupling
-Cooling type: Water cooling
-Residual oil content: Less than 3 ppm
-Oil volume: 200 liters
-Delivery air temp: Less than 40 degree
-Operating condition: Less than 45 degree of ambient temp
-Noise level: Less than 85 dB(A)
-Dimension: 5000mm*2500mm*2100mm
-Weight: 8500 kg
-Exhaust hole: G-5 inch
Famous brand and original air end is equipped with big diameter rotors hence it is of low rotate speed and high reliability. Multi-stages oil separation system makes air have low oil amount. Low speed centrifugal fanner makes cooling air amount big and noise low. Super cooling period design meets with the requirement under the environments of high temperature. There tare two cooling methods for every model, namely air-cooled and water-cooled.
| Pressure | | F.A.D | | Motor | | Noice | Oulet | Weight | net weight | package | Dimensions | Cooling | Driven | |
Model | Bar | Psi | L/min | CFM | Kw. | Hp | Db(A) | Connection | Kg | Kg | LxWxH(mm) | LxWxH(mm) | Type | Type | |
SC18 | 7 | 100 | 3,000 | 106 | 18.5 | 25 | 67 | G11/4 | 770 | 670 | 1200*1050*1650 | 1050*845*1450 | Air Cooling | Belt | |
SC22 | 7 | 100 | 3,600 | 127 | 22 | 30 | 69 | G11/4 | 800 | 700 | 1200*1050*1650 | 1050*845*1450 | Air Cooling | Belt | |
SC30 | 7 | 100 | 5,000 | 177 | 30 | 40 | 72 | G11/4 | 890 | 780 | 1400*1180*1900 | 1200*980*1700 | Air Cooling | Belt | |
SC37 | 7 | 100 | 6,700 | 237 | 37 | 50 | 72 | G11/4 | 920 | 810 | 1400*1180*1900 | 1200*980*1700 | Air Cooling | Belt | |
SC45 | 7 | 100 | 7,800 | 276 | 45 | 60 | 73 | G11/4 | 960 | 850 | 1400*1180*1900 | 1200*980*1700 | Air Cooling | Belt | |
SC55 | 7 | 100 | 10,500 | 371 | 55 | 75 | 74 | G2 | 1600 | 1400 | 1600x1340x1850 | 1400*1135*1700 | Air Cooling | Belt | |
SC75 | 7 | 100 | 13,500 | 477 | 75 | 100 | 80 | G2 | 1800 | 1500 | 2100x1460x1800 | 1900*1260*1600 | Air Cooling | Belt | |
SC90 | 7 | 100 | 16,200 | 572 | 90 | 125 | 82 | G2 | 2700 | 2500 | 2200x1500x1950 | 1900*1400*1750 | Air Cooling | Belt | |
SC110 | 7 | 100 | 20,000 | 707 | 110 | 150 | 82 | G2 | 2900 | 2700 | 2200x1500x1950 | 1900*1400*1750 | Air Cooling | Belt | |
SC132 | 7 | 100 | 23,500 | 830 | 132 | 175 | 82 | G2 | 3350 | 3100 | 1850x1600x2300 | 1650*1400*2150 | Air Cooling | Direct | |
SC160 | 7 | 100 | 28,000 | 989 | 160 | 220 | 82 | G2 | 4200 | 3900 | 1850x1600x2300 | 1650*1400*2150 | Air Cooling | Direct | |
SC200 | 7 | 100 | 33,000 | 1,166 | 200 | 270 | 84 | DN 80 | 4500 | 4200 | 2800x2000x2200 | 2500*1650*2200 | Air Cooling | Direct | |
SC250 | 7 | 100 | 42,000 | 1,484 | 250 | 340 | 84 | DN 80 | 4800 | 4500 | 2800x2000x2200 | 2500*1650*2200 | Air Cooling Direct | | |
