Product Specifications
| Prod Model: |
SUERPS12.1 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Weight: |
4.0kg |
| Size: |
12.1 Inch |
| Power: |
35W |
| Voltage: |
12V |
| USB: |
6* USB2.0 |
| Resolution: |
1024(RGB)X768(Xga) |
| COM: |
2*RS232 |
| BIOS: |
Ami32mbios |
| Working Environment: |
-30c_80c, 0-90 Ambient Humidity |
| Width :Height: |
16:9 |
| Screen Type: |
Capacitive Screen |
| Operating System: |
Windows |
| Memory: |
2GB |
| Webcam: |
Without Webcam |
| Built-in Microphone: |
Without Microphone |
| Network Mode: |
4G |
| Hard Disk Capacity: |
32G |
| Card Reader: |
Without Card Reader |
| Fingerprint: |
Fingerprint |
| CPU Core: |
Dual-Core |
| Battery Capacity: |
＞8000mAh |
| Screen Size: |
12.1 |
| CPU Type: |
Intel |
Product Description
Features
IP65 Waterproof Level
High Luminance Led Panel (400 nits)
Intel C1037U 1.80GHz Dual Core Processor
12.1"XGA 800 x 600 Resolution Color TFT Led Display
Ultra Slim and Compact Mechanical Design
Supports Wide Range DC Power Input (9-30V)
Wireless 3G/WIFI/GPS Can Be Customized
Processor
CPU
Intel C1037U 1.80GHz
Cache
Intel NM70
Memory
1*SO-DIMM,DDR3 1333\1066MHz Memory
Graphics Card
GMA 3600 ,640MHZ
Storage
Supports MSATA and Inner SATA2.5''
LAN
2×(RJ-45),10/100/1000 Mbps
I/O
Serial Ports
2×RS-232,(Extensible 5xRS-232,Supports RS485 ,Can be Customized)
USB Ports
Outer2×USB,Inner4×USB (extensible)
I/0
1 x HDMI,1 x VGA
Audio Interface
1 x Mic,1 x Line-out
1 x DC Port,1 x ON/OFF
1 x Mini-PCIE,1 x Mini-SATA
Weight
Net(kg)
4.0
Gross(kg)
4.5
Overall Dimension(L×W×D)
340×270×55
Installation Dimension(L×W)
See pictures
System
Windows XP,Windows XP Embedded,Win7,Win8,Linux ,etc
Power Supply
DC 9~30V
LCD Display
Type
12.1 Inch a-Si TFT-LCD
Panel Type
M150XN07 v2
Max Resolution
1024(RGB)×768(SVGA)
Display Color
262K(6-bit)
Contrast
500:1(Typ.)(transmission)
Visual Angel
60/60/35/65(Typ.)(CR≥10)(L/R/U/D)
Luminance
400 cd/m2 (Typ.)
Response Time
10/25(Typ.)(Tr/Td)(ms)
Pixel Pitch
0.264×0.264mm
Backlight
LED
Touch Panel
Type
4 Wire Resistive(AMT)
Resolution
Continuous
Optical Conduction
80%
Controller
USB Ports
Durability
35 Million Times
Environmental Parameter
Working Temp
-40ºC~80ºC
Working Humidity
10~95%RH@ 40ºC,Non-Condensing
Shock
10 G (11ms,Non-Operating)
Vibration
10 G
Certification
CE,FCC,ROHS
