2014 Hot Sale CNC Flat-Rotary Multi-Heads Carving Machinery

Product Specifications

Prod Model:	FCT-2018C&W-6S
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Model:	Fct-2018c&W-6s
Machine Size:	2552X3324mm
Flat Working Size:	2000X1800X200 Mm
Spindle Power:	2200W X6
Spindle Rotation:	6000~24000 Rpm
Tool Diameter:	3.175,4,12.7
Xyz Rails:	Pmi Square Rails
Mechincal Accuracy:	<0.03/300 Mm
Controlling Mode:	CNC
Feed Mode:	Mechanical
Spindle Layout:	Horizontal
Certification:	SGS
Spindle Number:	6

Product Description

Application:
Rotary engraving: Making relief on cylinder items, stair rail, handrail, desk or chair legs, tea-tray, the hunman body, avatar, buddha statue, etc.

Flat engraving: Antique reproduction furniture, Solid wood carving, arts and crafts carving, ornamental engraving, furniture-processing, instrument making, etc.

1. Multi heads greatly increased the production efficiency

2. The lathe is founded by industrial steel pipe welding, box-type structure which make it have large bearing capacity, strong rigidity. Special apparatus to eliminate welding stress that ensure machine's high stability.
3 High quality X, Y, Z imported ball screw or high accuracy gear rack transmission system, imported linear square rails
4 X, Y, Z high quality dust cover, effectively prevent dust come into the inside of machine.
5 Professional CNC control system, compatible with many CAM software such as Type3, artcam, mastercam, UG, pro-e etc.
6. It can work directly once you get the machine.


Special configuration:

We can produce larger size or special size according to customer's requirements, imported spindle, servo driver, auto-change tool system, oil lubrication apparatus, vacuum inhaling table, dust collector is optional.

Our service:
1. The machine comes with 1 year warranty;
When it exceed warranty period, if the machine's part need to be changed, we can sell to you at our cost price
2. Our technican could provide remote guide online if you need.
3. We are manufacturers specialized in CNC engraving and cutting machine, welcome to customize or distribute our machines.
4. If you have any questions or requirement, feel free to contact us, it's our honour to serve you.
