Gainer International (China) Limited >> 23dBm 1500sqm Coverage Dcs Power Signal Repeater

23dBm 1500sqm Coverage Dcs Power Signal Repeater

Name: 23dBm 1500sqm Coverage Dcs Power Signal Repeater
Brand: china-manufacturer-directory.com
SKU: 726020765
Availability: InStock
Rating: 4.3 (86 reviews)

Supplier:	Gainer International (China) Limited
Price:	Negotiable/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB,CIF,EXW

Product Specifications

Prod Model:	GCPR-D10 GCPR-D15 GCPR-D20 GCPR-D23 GCPR-D25
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Installation Type:	Indoor, Small Size
Technic Advantage:	Alc&Agc
Certificate:	CE RoHS ISO
Band:	GSM Dcs WCDMA Lte CDMA PCS Single Band
Output Power:	20 23dBm
Gain:	65db
20dBm Coverage:	800-1200sqm
23dBm Coverage:	1200-1500sqm
Work Environment:	Office Building,House,Coffe Shop etc
Package:	Neutral Packing
Type:	Wireless Repeater
Certification:	CE
Condition:	New

Product Description

23dBm 1500sqm Covearage Dcs Power Signal Repeater

Features:

1.With Oscillation Detective Indicate Function;

2..With Uplink/Downlink auto gain synchronization, can adjust the UL/DL gain;

3.High gain, easy installation and operation.

4.Use ALC and AGC technology, adjust extent automatically.

5.LED Light Working & Signal Condition Indicators.

6.Dependability stand by GB6993-86 standard.

7.Compatibility of electromagnetism according with ETS300 609-4.

Standard Package:
1) Power supply adapter 1 unit
2) AC power plug (USA/EU/Swiss/UK/SA/China standard etc) 1unit
3) Installation kit 1unit
4) User manual 1unit

Recommended Accessories:
1)Donor(outdoor) antenna:
For Single band repeater:Yagi Antenna(8dBi 10dBi)
For Dualband repeater:Patch Antenna(8.5dBi 806-960/1710-2700MHz)
For Triband repeater:Patch Antenna(8.5dBi 806-960/1710-2700MHz)

2)Service(indoor) antenna: Omni Ceiling Antenna (3dBi,806-960/1710-2700MHz)

3)2*15m of 50Ω-5 coaxial cable with 2 connecters.

We can make such as frequenies:

For indoor single band intelligent repeater: GSM900, GSM1800, GSM1900M, CDMA850, 3G2100, IDEN, LTE etc

For dualband and tri-band intelligent repeater: GSM900+GSM1800 dualband, GSM900+3G2100M dualband, 900+1800+2100 triband etc.

Outdoor series: Fullband repeater, band selective repeater, frequency selective repeater, frequency shifting repeater etc.

Model Number		GCPR-D10	GCPR-D15	GCPR-D20	GCPR-D23	GCPR-D25
Frequency		UL: 1710-1775MHZ or 1720-1785MHZ DL: 1805-1870MHz or 1815-1880MHZ
Output Power(Max)		10dBm	15dBm	20dBm	23dBm	25dBm
Gain		≥55dB	≥55dB	≥60dB	≥65dB	≥65dB
Automatic Level Control		≥20dB
Noise Figure		≤5dB
Gain Flatness		≤6dB (p-p),
Automatic Gain Control		30dB in step of 1dB (Auto)
Input Power Range		≤-25 dBm
IM3		≤-45dBc
Spurious Emission	9KHz~150KHz	≤-36dBm @ 1KHz
	150KHz~30MHz	≤-36dBm @ 10KHz
	30MHz~1GHz (out of band)	≤-36dBm @ 100KHz
	1GHz~6.7GHz	≤-36dBm @ 1MHz
Group Delay		UL≤1μs
Operating voltage		AC 220V
