Price: | US $ 28600/Set |
---|---|
Trade Terms: | FOB,CFR,CIF |
Min Order: | 1/Set |
Pay Type: | L/C,T/T |
INJECTION UNIT |
Unit | WMK-260 | |||
A | B | C | |||
Screw Diameter | Mm | 50 | 55 | 60 | |
Screw L/D Ratio | L/D | 24 | 21.8 | 20 | |
Short Size | Cm3 | 557 | 676 | 802 | |
Injection weight | G | 507 | 610 | 730 | |
Injection Rate | g/s | 121 | 146 | 174 | |
Plasticizing capacity | g/s | 32 | 42 | 49 | |
Injection Pressure | Mpa | 223 | 184 | 155 | |
Screw Speed | Rpm | 0-190 | |||
CLAMPING UNIT |
Clamp Force | KN | 2600 | ||
Space Between Tie Bars | mm | 560*530 | |||
Toggle Stroke | mm | 505 | |||
Max. Mold Height | mm | 560 | |||
Min. Mold Height | mm | 200 | |||
Ejector Stroke | mm | 150 | |||
Ejector Tonnage | KN | 62 | |||
Ejector Number | P | 9 | |||
OTHERS |
Max. pump Pressure | Mpa | 16 | ||
Pump motor powder | Kw | 22 | |||
Heater Power | Kw | 16 | |||
Machine Dimension(L*W*H) | M | 5.3*1.5*1.95 | |||
Oil Tank Capacity | L | 400 | |||
Machine Weight | T | 7.1 |
Prod Model: | wmk-400 |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Clamp Force: | 2600kn |
Max. Pump Pressure: | 16mpa |
Machine Dimension(L*W*H): | 5.3*1.5*1.95m |
Machine Weight: | 7.1t |
Automation: | Automatic |
Structure: | Horizontal |
Computerized: | Computerized |
Plastic Type: | Thermoplastic |
Type: | Injection Molding |
