28.3L/Min Flow Particle Counter Air Particle Counter Calibration

28.3L/Min Flow Particle Counter Air Particle Counter Calibration
Price: US $ 3900-4200/Piece
Trade Terms: FOB
Min Order: 1/Piece
Pay Type: T/T

Product Specifications

Prod Model: Y09-310LCD
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Outside Dim: 300*360*126 Mm
Display: LCD
Weight: 7.5kg
Power Source: DC 16.8V (Lithium Ion Battery)
Zero Count: <10min
Flow Rate: 2.83L/Min
Operating Time: 8 Hours
Location Labels: 0-999
Date Storage: 1000 Samples (with PC Software)
Environmental Temperature: 10degrees Celsius-35degrees Celsius
Certification: ISO
Type: Dust Laser Particle Counter

Product Description

Specifications

1.28.3L/min sample flow

2.AC-DC
3.automatic UCL calculation
4.small footprint


 28.3L/min Flow Particle Counter Air Particle Counter Calibration

The Model  Laser Particle Counter is used to detect the particles in the cleanroom. It can measure the class 100 to 300 k environment. The instrument uses the laser diode as the light source, LCD-panel displays, six different size ranges simul taneously. The built-in printer can print count results. The counter can store 1000 samples data. Software creates data files for viewing or export to EXCEL sheet to computer. The instrument is widely used in the fields of micro-electronics, precision machinery, optics, pharmacy and sanitation, biology, food and beverage, aerospace and so on.



Specifications



Outside Dim300*360*126 mm3; (Wide*Deep*High)
Weight7.5Kg
Max. Consumption48W
Power SourceDC 16.8V (Lithium Ion Battery)
Size Channels0.3, 0.5, 1, 3, 5, 10 μm
Calculation95%UCL calculation, Display Particle Concentration
Flow Rate28.3L/min (Imported Pump)
Sample Time1---10min (Selectable)
Zero Count10min
Location Labels0-999
PrinterBuilt-in Thermal Printer
Alarm10,100, 1000, 10000 ,100000,300000Class /ISO
Data Storage1000 Samples (With PC Software)
Light SourceLaser Diode (30, 000 hours Mean Time Between Failures)
Maximum Rated Particle Concentration35000 particles/L
Operating Time3 hours
Environmental Temperature10degrees celsius-35degrees celsius
Humidity20%-75%RH
Atmosphere Pressure86Kpa-106Kpa



Application



? Cleanroom Monitoring

? Facility Certification

?  Facility  Monitoring

? Filter Testing

? Cleanroom Laundries

? Cleanroom Packing

? Aerospace

? Hospital Surgical Rooms

? Pharmaceutical

? Paint Spray Booths

?Food Processing Area

?Hard Disk Drive Manufacturing
