Description:
1. Xaar proton printhead.
2. Separate ink pressure system, saving ink and decreasing the cost for the clients.
3. Removable leg, decreasing the freight of the clients.
4. Photoelectricity sensor and automatic correction system.
5. Three-heating system: Pre-heater, printer heater, and after heater, adjust the suitable temperature of the media, increase the printing quality.
6. Use the ink which certified by Xaar, increase the speed 70% base on the original speed.
PACKING SIZE: 4760*950*1350mm
Net Weight/Gross Weight: 650KG/750KG
|
Model |
LA3208XR382 |
|
Printing Type |
Separation Printing |
|
Printing Technology |
Piezo printing |
|
Printhead Type |
XAAR PROTON Printhead(8 printheads) |
|
Media Transmmision |
Roll to Roll |
|
Printing Port |
High speed USB boards |
|
Data Transmission |
Fabric Cable |
|
Output Model |
Rip Printing/Printing After RIP/Net-print |
|
RIP Software |
Photoprint, Ultraprint |
|
Printing Mode |
4 Colors with 8 printheads |
|
Speed |
High speed: |
240*360dpi: 120 m 2 /h 1pass; 50 m 2/h 2pass |
|
Mid speed: |
240*540dpi: 35 m 2 /h 3pass |
|
Low speed: |
360*720dpi: 20 m 2 /h 4pass |
|
Heating System |
Four Heaters: front heater+bed heater+rear heater+printhead heater |
|
Cleaning System |
Air Pressure and Suction Cleaning |
|
Frame Structure |
Steady steel structure is used on the machine body, and the combination of aluminum and steel on the girder |
|
Color |
C, M, Y, K |
|
Power Requirement |
220V AC |
|
System |
220V± 10%, < 4A, 50/60HZ |
|
Heating |
220V± 10%, < 16A, 50/60HZ |
|
Operation Environment |
Temperature: 20° C∼ 25° C; Humidity: 40%∼ 70%RH |
|
Printing Resolution |
Ajustable(From 240dpi, 360dpi to 1440dpi) |
|
Media Types |
Banner, Adhesive Vinyl, PVC Self-Adhesive, Backlit Film, Flex media within 5mm thickness |
|
Printing/Media Width |
1800mm, 2500mm, 3200mm |
