Product Specifications
Product Description
Apparatus
Solar cells and modules:3000Wp;
Free maintenance battery:1000AH/48V;
Inverter:5000W
Charge controller:60A;
Supply for rainy days: 3 days
Supply the electricity for these appliances below:
NameWatt of LoadQuantityWorking hours per dayConsumption per day
Lamp 11W86528Wh
Computer100W251000Wh
Printer250W11250Wh
Refrigerator100W124800Wh
Washer300W10.5150Wh
Microwave oven1000W10.5500Wh
Air conditions1800W154000Wh
TV250W161500Wh
Total3811W8728Wh
Stand-alone PV Power System (off-grid)
System includes:
1. PV Array: A number of PV panels connected in series and/or in parallel giving a DC output out of the incident irradiance. Orientation and tilt of these panels are important design parameters, as well as shading from surrounding obstructions.
2. PV controller: control battery bank charge and discharge reasonable and safety.
3. Inverter: A power converter that "inverts" the DC power from the panels into AC power. The characteristics of the output signal should match the voltage, frequency and power quality limits in the supply network.
4. Battery bank: can be a single battery or multiple batteries connected together to create essentially one large battery of the required voltage and amp-hour capacity. In some ways the battery configuration and capacity are the most important electrical power decision to make, and a wise choice can help guarantee a steady supply of electrical power as well as a system that is simple to operate and maintain.
5. Loads: Stands for the network connected appliances in the building that are fed from the inverter, or, alternatively, from the grid
.
Grid-connected PV system
Grid Connected PV system design has the following components:
1. PV Array or Generator: A number of PV panels connected in series and/or in parallel giving a DC output out of the incident irradiance. Orientation and tilt of these panels are important design parameters, as well as shading from surrounding obstructions.
2. Inverter: A power converter that "inverts" the DC power from the panels into AC power. The characteristics of the output signal should match the voltage, frequency and power quality limits in the supply network.
3. Loads: Stands for the network connected appliances in the building that are fed from the inverter, or, alternatively, from the grid.
4. Meters: They account for the energy being drawn from or fed into then local supply network.
5. Local Supply Network: A single or three-phase network managed by a Public Electricity Supplier. The supply network acts both as a sink for energy surplus in the building or as a backup for low local generation periods.
