Product Specifications
| Prod Model: |
3800mm |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Process: |
Paper Machine |
| Usage: |
Packing Paper Machine |
| Automatic Grade: |
Semiautomatic |
| Computerized: |
Yes |
| Type: |
Paper Machine |
| Certification: |
ISO |
Product Description
3800mm fluting paper production line with 110T/D
Technical parameters
Raw material waste paper
Output paper fluting paper, kraft paper
Output weight 100-200g/m2
Net paper width 3800mm
Wire width 4200mm
Working speed 1 50-180mmin
Design speed 200m/min
Capacity 80-110 ton/day
Rail gauge 5000mm
Drive way Alternating current frequency converter speed control, sectional drive.
II. Structure and specifications of main equipment
1. Cylinder part: 1800mm× 4200mm× 5000mm stainless cylinder mold 2 pcs, 550mm× 4200mm× 5000mm couch roll 2 pcs, rubber shore hardness 38± 2,
600mm× 4200mm× 5000mm drum roll 1 pc, rubber shore hardness 85± 2
2. Press part: 950mm× 4200mm× 5000mm natural marble roll 2 pcs, 900mm× 4200mm× 5000mm rubber roll 2 pcs, rubber shore hardness 95± 2
3. Dryer part: 1500mm× 4200mm× 5000mm alloy dryer cylinder 26 pcs, with
Scrapers 26 sets.
4. Sizing part: Top roll 1 pc, 1000mm× 4200mm× 5000mm imitation stone roll, bottom roll 1 pc, 1005mm× 4200mm× 5000mm rubber roll. Rubber shore hardness 95± 2
Arrangement mode: 18+sizing machine+8
5. Winding part: 3800mm horizontal pneumatical winding machine 1 set,
6. Rewinding part: 3800mm frame-style rewinding machine 1 set
Company:
We are a professional paper machine manufacturer
Here, you can get the whole production line
We promise you good quality machines cause we do only one thing---paper machine
So welcome to visit and negotiate
Perfect service:
1. Technical consultation
2. Plant design
3. Installation and test run
4. Training engineers and workers
5. Good and long time after-sale service
Our company has over 420 employees. There are five factories in China with the total area of 20, 000m2, it has passed the ISO14001 international authentication
Our products include paper making machines, parts and paper processing machines such as kraft paper machine, tissue paper machine, cultural paper machine, fiber separator, hydrapulper, rewinder, napkin folder, tisue slitter and ao on. They have been exported to more than 8countries and regions, such as America, Russia, Brazil, Indonesia, Fiji, etc. Relying in perfect & advanced technology, sincere service and inexpensive products with high quality, we have won the recognition of international market and clients
Why choose us
Our company gathers a technique team of engineers and experts with over 30 years' experience which helps us be a professionall on all kinds of paper making machines and make us competitive on the market. We focus on quality and customers' need and improve our technology and service continually. We believe our devotion to work will help us to achieve global leadership in providing first-class products and superior quality services to customers around the world
Our advantages
Technical advantage
1. Experiences producing team
2. Advanced technological strength
Product advantage
1. Through the international authentication
2. Same material with most preferential price
3. A lot of varieties for the customer to choose
Service advantages
1. Technical consultation
2. Project evaluation
3. Detailed design of factory
4. Installation and test the whole production line
5. Training engineers and workers
6. Supplying spare parts for long time
