Blissum's RFC-H series filling machines are designed especially for bottling synthetic juices (RTS) or HOT filled juices, tea (filled at up to 98 centigrade degrees), with optional capacity ranging from 1000BPH to 32000BPH, it adopts the pressure & rotative filling style.
1. Centre filling valves used which are designed for maximum flow rate and minimum bottle distortion during HOT filling.
2. Inbuilt CIP arrangement provided on the machine for fill tank and fill valve sanitation.
3. Dummy caps provided fitting on all filling valves during CIP.
4. Automatic PLC controlled valve washing cycle before commencement of every production cycle for overall hygiene.
5. Unique filling cam designs which prevents filling up to the bottle collar without spillage.
6. Bypass line provided for flushing the product fill tank after completion of CIP
7. Supper heavy stainless steel juice tank build in
Technical Parameter of Juice bottling machine/production line:
Model(RFC-H) | 14-12-5 | 16-16-5 | 24-24-8 | 32-32-8 | 40-40-10 | 50-50-15 |
washing,filling,sealing(No.) | 14-12-5 | 16-16-5 | 24-24-8 | 32-32-8 | 40-40-10 | 50-50-15 |
Production capacity(bottle/hour) (500ml) | 3000-5000 | 5000-8000 | 8000-10,000 | 12,000 | 15000 | 18000-20000 |
Suitable bottle height (mm) | H=160-310 φ=50-110 |
Total Power (kw) | 2.42 | 3.12 | 3.92 | 3.92 | 5.87 | 7.87 |
Overall dimension(L×W×H) (mm) | 2360x1770x2700 | 2760x2060x2700 | 2800x2230x2700 | 3550x2650x2700 | 4700x3320x2700 | 5900x4150x2700 |
Weight (kg) | 3500 | 4000 | 4800 | 6800 | 8500 | 1000 Why Choose Us |
Why choose us:
1. Each water filling machine element tha contacts with the liquid is made of high quality Stainless steel 304, if needed, SS 316 is also available.
2. The water filling machine adopts bottle neck holding transmission technology to realize fully automatic rinsing, filling and capping.
3. Most elements of the electrical system use famous international brand, such as Mitsubish, Omron brand.
4. The water filling machine obtain the advantages of good abrasive resistance,high stability,low failure rate, etc. The
quality of the equipments reaches the international advanced level.
5. Advanced technologies, human-machine interface touch screen and PLC program control are adopted in this machine.
6. Nozzles in the grab can guarantee the complete wash of the interior of the bottle.
7. Easy to operate, save the cost of workers.
Established in 2002, Blissum is one of the professional & reliable China manufacturers & provide of liquid & semi-liquid filling machinery, sealing capping machinery & other liquid packaging machinery with reliable machine quality & after sale service!
Our extensive experience of liquid & semi-liquid filling & packaging and container handling enables us to offer complete solutions to designs, manufactures, supplies, installs, maintains, troubleshoots, and upgrades plants for complete processing and packaging lines with special emphasis on bottling in glass, PET, Jar, can, and kinds of container
With a flexible approach, we are able to provide the right solutions for a diverse customer base, from small start up companies through to major national companies. Our many satisfied customers come from a very wide range of industries, including toiletries, cosmetics, pharmaceuticals, food, drink, household products and chemicals.
Blissum with ethos focus on after sale customer service, strive to achieve excellence, from our initial response to your enquiry to our after sales support and spares service.
