| Price: | Negotiable/Piece |
|---|---|
| Trade Terms: | FOB |
| Min Order: | 100/Piece |
| Pay Type: | T/T,Paypal,Western Union |
Feature:
Specification:
| Printing method: | Thermal |
| Number of dots: | 384 |
| Resolution (dots/mm): | 8 |
| Printing width (mm): | 48 |
| Paper width (mm): | 58 |
| Max. paper thickness (um): | 80 |
| Paper loading: | Easy loading |
| Printing speed (mm/s): | 85 |
| Paper detection: | Opto sensor |
| Temperature detection: | Thermistor |
| Head-up or Cover-open detection: | Combined with opto sensor |
| Voltage range (Logic/Head): | 2.7-5.25 / 2.7-7.2or4.5-8.5V |
| Dot resistance (Ohm): | 123/176 ± 4% |
| Energy per dot (mJ): | 0.15 |
| Stepper motor (Ohm): | Bipolar (12) |
| Weight (g): | 40 |
| Life/reliability: | 50km/100M pulses |
| Operating temperature (C): | 0 to 50 non cond. |
| Operating humidity (%): | 20 to 85 non cond. |
| Dimensions (WxDxH mm): | 68.3x41x15 |
Application:
Xiamen Cashino Electronic Technology Co.,LTD.is highly specialized in designing, developing, manufacturing and marketing of printing equipments; and provide the professional printing solution. with the factory located in Xiamen city.
With rich of experience and professional R&D team, Cashino successfully launched a series of printing equipments. Such as portable printer,bluetooth printer,micro panel printer, Kiosk printer,POS receipt printer, barcode label printer, as well as printer mechanism( thermal & impact type) and so on;Our products usually are used for POS/ECR, Transport Ticketing , Instrument Analyzers, KIOSK system, Electronic medical equipment, self-service solution etc.
In recent years, as the market is increasingly mature and growing, Cashino's business have expand to oversea markets, such as Southeast Asia, South Asia, South & North America, Middle East and Europe, etc. Won the majority of worldwide customers' favor. In view of having a strong R&D team, we also provide OEM/ODM service for customers.
Cashino always keep up with the enterprise goal of "survival by quality, service for development". We are able to provide all customers with high quality products to meet their strict requirements at competitive prices. Ultimately we wish to establish and maintain a long-term relationship with every customer built on respect, confidence and Mutual benefit.
| Prod Model: | TP-205MP |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Products Status: | Stock |
| Black Print Speed: | 80mm/S |
| Compatible With: | Aps MP-205LV/Hs |
| Paper Supply Method: | Straight Ahead |
| Printing Life: | 50km/100m Pulses |
| Max. Resolution: | 8dots/Mm |
| Place Of Origin: | Fujian China (Mainland) |
| Weight (G): | 40 |
| Effiective Printing Width: | 48mm |
| Dimension (Wxdxh Mm): | 68.3X41X15 |
| Usage: | Barcode Printer |
| Style: | Black and White |
| Interface Type: | RS232/Ttl |
| Type: | Thermal Line Printing |
| Max. Paper Size: | 58mm |
| Character Structure: | Ascii, GB2312 |
