Yueqing Shangjing Rectifier Co., Ltd. >> AC &DC Motor Control Dis Thyristor

AC &DC Motor Control Dis Thyristor

Name: AC &DC Motor Control Dis Thyristor
Brand: China-Manufacturer-Directory.com
SKU: 663448121
Availability: InStock
Rating: 5 (52 reviews)

Supplier:	Yueqing Shangjing Rectifier Co., Ltd.
Price:	Negotiable/Piece
Min Order:	12/Piece
Quantity::
Trade Terms:	FOB

Product Specifications

Prod Model:	ST500C
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Manufacturing Technology:	Logic IC
Material:	Element Semiconductor
Type:	Intrinsic Semiconductor
Package:	Intertional Standard Package
Application:	Big Power Transformer, Motor Control ,Inverter
Model:	St500c
Batch Number:	2015+
Brand:	Shangjing

Product Description

Features
Total diffusion process
Ceramic disc type seal
Central amplifying gate structure
Double-sided cooling
Heavy current

Typical Applications
High-power converter
AC & DC motor control
AC & DC switch
Phase control rectification
Inverter

Explanation
IGT, VGT, IH are TA=25° C test data, others are all TA=Tjm test data.
I2t=I2TSM× TW/2: TW=Half sine wave current when at 50Hz, I2t=0.005I2FSM(A2S)
When at 60Hz ITSM(8.3ms)=ITSM(10ms)× 1.066, Tj=Tjm
I2t(8.3ms)=I2t(10ms)× 0.943, Tj=Tjm

Type	V_DRMV_RRM	I_T(AV)	I_TSM	dv/dt	di/dt	I_DRMI_RRM	I_GT	V_GT	I_H	V_TM/I_TM	R_th(j-hs)	T_jm	M 2	Outline
		T_HS55° C	10ms				25° C
	V	A	kA	V/μ s	A/μ s	mA	mA	V	mA	V/A	° C/W	° C	kN
ST200C	200-3000	200	2.5	300	100	30	35-250	0.8-2.0	20-150	2.3/600	0.065	125	5.3-10	E1/E2
ST300C	200-3000	300	3.8	300	100	30	35-250	0.8-2.5	20-200	2.1/900	0.055	125	5.3-10	E1/E2
ST400C	200-3000	400	5	300	100	40	35-250	0.8-2.5	20-200	2.3/1200	0.040	125	10-20	E1/E2
ST500C	200-5000	500	6.4	300	100	50	35-250	0.8-2.5	20-250	2.3/1500	0.035	125	15-20	E2/E3/E5
ST600C	200-5000	600	6.4	300	100	40	35-300	0.8-2.5	20-250	1.7/1800	0.035	125	10-20	E2/E3/E5
ST800C	200-5000	800	10	300	100	5080	40-300	0.8-3.0	20-250	2.1/2400	0.032	125	15-20	E5/E6
ST1000C	200-5000	1000	13	500	150	120	40-300	0.8-3.0	20-300	2.3/3000	0.022	125	21-30	E6/E8
ST1200C	200-5000	1200	15	500	200	120	40-300	0.8-3.0	20-300	2.3/3000	0.020	125	21-30	E8
ST1500C	200-5000	1500	20	500	200	160	40-300	0.8-3.0	20-300	2.3/3000	0.017	125	27-34	E8/E9
ST1800C	200-5000	1800	22.5	500	200	200	40-300	0.8-3.0	20-300	2.3/4000	0.016	125	30-40	E11/E12/E13
ST2000C	200-5000	2000	25	500	250	200	40-300	0.8-3.0	20-300	2.3/4000	0.011	125	35-47	E11/E12/E13
ST2500C	200-5000	2500	31	500	250	200	40-300	0.8-3.0	20-300	2.3/5000	0.011	125	35-47	E11/E12/E13
ST3000C	200-5000	3000	38	500	250	250	40-300	0.8-3.0	20-300	2.1/5000	0.011	125	35-47	E14/E15
ST3500C	200-5000	3500	44	500	250	250	40-300	0.8-3.0	20-300	2.3/5000	0.01	125	70-85	E14/E15
ST4000C	200-5000	4000	48	500	250	250	40-300	0.8-3.0	20-300	2.3/5000	0.01	125	70-85	E14/E15
ST4500C	200-5000	4500	54	500	250	250	40-300	0.8-3.0	20-300	2.2/5000	0.01	125	70-85	E15
ST5000C	200-5000	5000	60	500	250	250	40-300	0.8-3.0	20-300	2.3/5000	0.01	125	70-85	E15

China Shangjing Rectifier Co., Ltd. Was co-founded by China DELIXI Group, Shanghai Rectifier Co., Ltd. And Jingtai Electric Co., Ltd. In 1999. As one of the most professional manufacturers of power semiconductors and silicon rectifying whole set equipments, our company has been devoted to provide the high quality semiconductor products for our customers all over the world.
Shangjing Rectifier Co., Ltd. is located in Liushi Town which is well known as the "Capital of Electric City" in China. We are very close to the Wenzhou Airport and the deep-water sea port, which makes it very easy for us to reach our customers from the whole world.

Our company has been certified by China Industrial Department and we have got CE certificate. Furthermore, our products are compliant to the latest RoHS directions.

We have brought advanced technologies and equipment from abroad and kept improving our management and products quality. We stick the spirit of "Chasing for high quality and Servicing our clients with all our heart and credibility", we have gained a lot of honors like "AAA class China quality & credibility company", "member of China Electric Industry Association", etc. We have been exporting our products to Europe, South and North America, Middle East, Africa and earned a lot of good feedback.

We hope our high quality products and service will be bringing successful future to all our customers.
