Stud Type Standard Recovery Diode

Name: Stud Type Standard Recovery Diode
Brand: china-manufacturer-directory.com
SKU: 674445242
Availability: InStock
Rating: 4.6 (34 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB
Min Order:	100/Piece
Pay Type:	T/T,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Product Specifications

Prod Model:	70HF(R) DO-5
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Manufacturing Technology:	Logic IC
Material:	Element Semiconductor
Type:	Intrinsic Semiconductor
Package:	International Standard Package
Application:	Motor Control, Welder
Model:	70hf(R) Do-5
Batch Number:	2015+
Brand:	Shangjing

Product Description

Features
High surge current capability
Stud cathode and stud anode version
Wide current range
Metric device version available

Typical Applications
Battery charges
Converters
Power supplies
Machine tool controls
Welder
Motor controls

Type	I_F(AV)	V_FM/I_FM		I_F(RMS)	V_RRM	I_RRM	R_jc	T_j	M2	Wt	Outline
	T_HS55° C	25° C
	A	V	A	A	V	mA	° C/W	° C	kN	kg
6F(R)	6	1.00	18	9.0	200-1200	≤ 6	≤ 2.0	-40 ~ +150	≤ 1.0	0.008	DO-4
12F(R)	12	1.10	36	19.0	200-1200	≤ 6	≤ 1.2		≤ 1.0	0.008
16F(R)	16	1.10	48	25.0	200-1200	≤ 12	≤ 1.2		≤ 1.0	0.008
25F(R)	25	1.10	75	40.0	200-1200	≤ 12	≤ 1.2		≤ 1.0	0.008
30HF(R)	30	1.20	90	48.0	200-1200	≤ 10	≤ 0.8		≤ 2.0	0.020	DO-5
40HF(R)	40	1.20	120	64.0	200-1200	≤ 10	≤ 0.8		≤ 2.0	0.020
50HF(R)	50	1.30	150	80.0	200-1200	≤ 10	≤ 0.8		≤ 2.0	0.020
60HF(R)	60	1.30	180	96.0	200-1200	≤ 12	≤ 0.6		≤ 2.0	0.020
70HF(R)	70	1.35	210	112.0	200-1600	≤ 12	≤ 0.5		≤ 2.0	0.020
85HF(R)	85	1.35	255	136.0	200-1600	≤ 12	≤ 0.4		≤ 2.0	0.020
100U(R)	100	1.70	300	160.0	200-1600	≤ 15	≤ 0.3		≤ 12	0.120	DO-8
150U(R)	150	1.40	450	240.0	200-1600	≤ 15	≤ 0.3		≤ 12	0.120	DO-8
100U(R)L	100	1.70	300	160.0	200-1600	≤ 15	≤ 0.3		≤ 12	0.140	DO-30
150U(R)L	150	1.40	450	240.0	200-1600	≤ 15	≤ 0.3		≤ 12	0.140	DO-30
200U(R)	200	1.20	600	320.0	200-1800	≤ 20	≤ 0.2		≤ 12	0.250	DO-9
250U(R)	250	1.25	750	400.0	200-1800	≤ 20	≤ 0.15		≤ 25	0.250
300U(R)	300	1.25	900	480.0	200-1800	≤ 20	≤ 0.15		≤ 25	0.250
SD400N(R)	400	1.50	1200	640.0	200-2400	≤ 40	≤ 0.07		≤ 25	0.580	B-8
SD500N(R)	500	1.50	1500	800.0	200-2400	≤ 40	≤ 0.065		≤ 25	0.580
SD600N(R)	600	1.40	1800	960.0	200-2400	≤ 40	≤ 0.065		≤ 30	0.580

China Shangjing Rectifier Co., Ltd. Was co-founded by China DELIXI Group, Shanghai Rectifier Co., Ltd. And Jingtai Electric Co., Ltd. In 1999. As one of the most professional manufacturers of power semiconductors and silicon rectifying whole set equipments, our company has been devoted to provide the high quality semiconductor products for our customers all over the world.
Shangjing Rectifier Co., Ltd. is located in Liushi Town which is well known as the "Capital of Electric City" in China. We are very close to the Wenzhou Airport and the deep-water sea port, which makes it very easy for us to reach our customers from the whole world.

Our company has been certified by China Industrial Department and we have got CE certificate. Furthermore, our products are compliant to the latest RoHS directions.

We have brought advanced technologies and equipment from abroad and kept improving our management and products quality. We stick the spirit of "Chasing for high quality and Servicing our clients with all our heart and credibility", we have gained a lot of honors like "AAA class China quality & credibility company", "member of China Electric Industry Association", etc. We have been exporting our products to Europe, South and North America, Middle East, Africa and earned a lot of good feedback.

We hope our high quality products and service will be bringing successful future to all our customers.
