ACR38F Floppy Bay Smart Card Reader
Product Specifications
| Prod Model: |
ACR38F |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: |
125mm (L) X 101.5mm (W) X 25.5m (H) |
| Dimensions: |
125mm (L) X 101.5mm (W) X 25. |
| Supply Voltage: |
Regulated 5V DC |
| Clk Frequency: |
4 MHz |
| Mbtf: |
500, 000 Hours |
Product Description
ACR38F Smart Card Reader Floppy
IntroductionThe ACR38F Smart Floppy is the ideal solution for an easy integration of smart card readers into the desktop environment. It uses the same core as the ACR38 Smart Card Series, and shares the versatility and cost-efficiency that customers have always associated with ACS smart card readers. Using the USB interface, it is propelled by the PC's internal power supply, and can be configured to suit customer preferences.
Similar to ACR38, the ACR38F Floppy Bay Smart Card Reader is very user-friendly. ACR38F is now CCID-compliant, enabling its plug-and-play feature that eliminates the need for driver installation and driver-system compatibility assessment. It is ideal for a wide variety of smart card applications such as electronic commerce, home banking, e-purse facility and secure computer access.
FeaturesSupports ISO-7816 Class A, B and C ( 5V, 3V, 1.8V ) cards
Performs read and write operations on all microprocessor cards with T=0, T=1: 500, 000 hours
Smart Card Interface Support: ISO-7816 Class A, B and C ( 5V, 3V, 1.8V )
Compliance/Certifications: *EN 60950/IEC 60950, EMV 2000 Level 1, PC/SC, CCID, CE, FCC, RoHS Compliant, USB Full Speed
*Microsoft WHQL: 2000, 2003, XP, VISTA, 2008, 2008 R2, 7
Operating System Support *Win98, Win ME, Win 2000, Win XP, Win Vista, Win 7, Win Server 2003, Win Server 2008
*Win XP x64, Win Vista x64, Win 7 x64, Win Server 2003 x64, Win Server 2008 x64, Win Server 2008 R2 x64
*Mac
*Linux
|
Dimensions |
125mm (L) x 101.5mm (W) x 25.5m (H) |
|
Interface |
USB 2.0 full speed |
|
Supply Voltage |
Regulated 5V DC |
|
Supply Current |
Max. 50mA |
|
Operating Temperature |
0-50°C |
|
CLK Frequency |
4 MHz |
|
MBTF |
500,000 hours |
|
Smart Card Interface Support |
ISO-7816 Class A, B and C ( 5V, 3V, 1.8V ) |
|
Compliance/Certifications |
-EN 60950/IEC 60950, EMV 2000 Level 1, PC/SC, CCID, CE, FCC, RoHS Compliant, USB Full Speed
-Microsoft WHQL: 2000, 2003, XP, VISTA, 2008, 2008 R2, 7 |
|
Operating System Support |
-Win98, Win ME, Win 2000, Win XP, Win Vista, Win 7, Win Server 2003, Win Server 2008
-Win XP x64, Win Vista x64, Win 7 x64, Win Server 2003 x64, Win Server 2008 x64, Win Server 2008 R2 x64
-Mac
-Linux |
