Product Specifications
| Prod Model: |
7215AC/DF 7215AC/DT 7215B/DB 7215B/DF |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: |
Customized |
| Rolling Body: |
Ball Bearings |
| The Number Of Rows: |
Single |
| Outer Dimension: |
Extra Large (',440mm) |
| Material: |
Bearing Steel |
| Load Direction: |
Radial Bearing |
| Separated: |
Unseparated |
Product Description
Feature
A, which can also bear radial and axial load or axial load
B, running resistance is small, the limit speed is high
C, high rotation accuracy
D, low noise and vibration
E, single row angular contact ball bearings can only bear a direction of the axial force, is usually used to balance the axial force
Product application:
Machine tools, precision instruments, automotive, fluid transportation machinery, light industry machinery, etc.
Bearing No.(New) | Bearing No.(Old) | Inner Diameter(Mm) | External Diameter(Mm) | Width(Mm) | Cr(Kn) | Cor(Kn) | Grease Lubrication Speed(R/Min) | Oil Lubricatin Speed(R/Min) | Weight(Kg) |
| 7215AC/DF | 346215 | 75 | 130 | 50 | 129 | 130 | 4600 | 5800 | 2.46 |
| 7215AC/DT | 446215 | 75 | 130 | 50 | 129 | 130 | 4600 | 5800 | 2.46 |
| 7215B/DB | 266215 | 75 | 130 | 50 | 116 | 119 | 3500 | 4600 | 2.46 |
| 7215B/DF | 366215 | 75 | 130 | 50 | 116 | 119 | 3500 | 4600 | 2.46 |
| 7215B/DT | 466215 | 75 | 130 | 50 | 116 | 119 | 3500 | 4600 | 2.46 |
| 7215C/DB | 236215 | 75 | 130 | 50 | 140 | 141 | 6400 | 8500 | 2.46 |
Q: Could I customized this kind of product from your factory?
A: Of course. We can offer OEM service to our clients. Please provide us some technical data such as dimension and marking.
Q: What is the best way to maintain my bearings?
A: 1) Soak your bearings in mineral spirits or paint thinner to remove any grease or particulates.
2) Blow bearing out with compressed air.
3) Place a light drop of oil on the bearing.
4) Give the bearing a spin.
Q: Could you give me a discount?
A: Since we are a factory, our policy is that the bigger order quantity, the lower quotation will be. So we will give you a discount according to the size of order.
Shanghai Shengjian Bearing Co., Ltd is the new sub-branch of Shandong Shengjian Bearing Co., Ltd, which is specilized in bearing design, R&D, manufacturing and sales for 15 years.
We are committed to manufacturing and providing bearings of high quality, high stability and long life span with advanced technology and strict qualtiy control system like heat treatment, grinding, assembly, testing to meet customers requirements.
Our production line: Deep groove ball bearings, Spherical ball bearing, Thin section bearing, Thrust ball bearing, Thrust roller bearing, Cylindrical roller bearing, Tapered roller bearing, Needle roller bearing, Rod end bearing, Angular contact ball bearing, etc.
Based on long-term elaborately research and advanced management concept, We carefully do every point, every drop for the customers to creat "win-win"
Our advantages:
1. Competitive price, high quality
2. OEM service
3. Timely delivery
4. Large stocks
5. ISO 9001: 2008
We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective.
