Price: | Negotiable/Piece |
---|---|
Trade Terms: | FOB |
Min Order: | 1/Piece |
Pay Type: | L/C |
Technical Specification | ||||
Model | XYQ3B/3C | XYQ6B | XYQ12A | |
pipe size range of master tong | mm | φ60~89 | φ73~114 | 60~140 |
in | 2 3/8~3 1/2 | 2 7/8~4 1/2 | 2 3/8~5 1/2 | |
pipe size range of backup tong | mm | φ60~114 | φ89~141.5 | φ73~156 |
in | 2 3/8~ 3 1/2 | 2 7/8~4 1/2 | 2 3/8~5 1/2 | |
high gear rated torque | kN.m | 1.1 | 1.5 | 2.6 |
lbf.ft | 811 | 1106 | 1918 | |
low gear rated torque | kN.m | 3 | 6 | 13 |
lbf.ft | 2213 | 4425 | 9588 | |
high gear rated speed | r/min | 100 | 85 | 68 |
low gear rated speed | r/min | 30 | 20 | 13 |
rated operation pressure | Mpa | 10 | 11 | 12 |
psi | 1450 | 1595 | 1740 | |
max. flow | L/min | 80 | 100 | 120 |
gpm | 21 | 26 | 32 | |
dimension | mm | 650×430×550 | 750×500×600 | 1042×582×839 |
in | 25.6×16.9×21.7 | 29.5×19.7×23.6 | 41×22.9×33 | |
weight (including backup tong | kg | 158 | 220 | 471 |
lb | 348 | 485 | 1038 |
Markets: | Eastern Europe,Southeast Asia,Mid East |
---|---|
