Asynchronous Full Color P10 Outdoor Advertising LED Display, Electronic Information Board, LED Display Control Software
| Price: |
US $ 8/Piece |
| Trade Terms: |
FOB |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,D/P |
Specifications
1.high brightness
2.high resolution
3.long life span
4.good waterproof
P10 Outdoor fullcolor led display/ innovative new led screen billboards/sex hot led video
Part Number | HERO-IDS10F-4S |
Resolution | 16(H)×16(V) |
Pixel Pitch | 10mm |
LED Configuration | 1R1G1B DIP |
Pixel Density | 10,000 pixels/ m2 |
Module Size | 160×160mm |
Cabinet Size | |
Driving IC | MBI5024 |
Driving Method | 1/4 Scan, Constant Current |
Weight | 42KG/sq.m. |
Mechanical Ratings |
Hanging Weight Support | 2T |
Surface Flatness | Gap<0.5mm |
Optical Ratings |
Brightness | >6500cd/ m2 |
View Angle | 110°/70° |
Gray Scale | 8bits input, correction with 14bits |
Display COLOR | 16.7M |
Brightness Adjustment | 0~100% 10 level |
Power Supply |
Operation Power | 90~260V 50~60Hz |
Max. Power Consumption | 1000W/ m2 |
Average Power Consumption | 320W/ m2 |
Control System |
Control Mode | Synchronous display with control PC by DVI |
Frame Update Frequency | 60~85Hz |
Screen Refresh Frequency | 300~1000Hz |
Gamma Correction | -5.0~+5.0 |
Support Input | Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI |
Control Distance | Ethernet cable<120m or Fiber Optic<10Km |
Support VGA Mode | 1024×768, 1280×1024, 1600×1200, 1920×1280 |
Brightness Correction | Pixel, Module, Cabinet |
Environmental |
Operating Temperature | -20°~+60° |
Operating Humidity | 10~95% RH |
Operating Life | 100,000hours |
MTBF | 5000hours |
Protection Level | IP65 |
Out o f Control Rate | <0.02% |
| Prod Model: |
P10 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| LED Type: |
DIP346 |
| Scan Mode: |
1/4 |
| Brightness: |
>6500CD/ M2 |
| Viewing Angle: |
110/70 |
| Refresh Rate: |
300~1000Hz |
| Lifespan: |
More Than 100,000 Hours |
| Max. Power Comsumption: |
1000W/ M2 |
| Average Power Consumption: |
320W/ M2 |
| Mtbf: |
5000hours |
| Warranty: |
3 Years |
| Tube Chip Color: |
Full Color |
| Display Function: |
Video Display |
| Pixel Pitch: |
10mm |
| Pixel Configuration: |
1R,1G,1B |
| Pixel Density: |
10,000 dots / m² |
| Scanning Mode: |
1/4 Scan |
| Display Type: |
LED Video Display |
| Application: |
Shopping Guide |
| Certification: |
ETL |
| System Operating Platform: |
General |
| IP Rating: |
IP65 |
