Automatic Full UV Label Flexo Printing Machine
Product Specifications
| Prod Model: |
QT-320-5C |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Anilox Roller: |
Ceramic |
| Doctor Blade: |
1PC/ Color |
| Die-Cutting Unit: |
1unit |
| Type: |
Ink Jet Type |
| Structure: |
Rotary Printing Press |
| Style: |
Flexographic Printing Presses |
| Color & Page: |
Multi-Colour Printing Press |
| System Supported: |
No |
| Print Interface: |
No |
Product Description
Automatic Full UV Label Flexo Printing MachineFunctional characteristics:1. The main motor is adopted the import stepless regulation of frequency conversion.
2. Unwinding and rewinding are controlled by magnetic powder brake, clutch ( or by automatic tension controller of Mitsubishi, made in Japan. )
4. One ceramic anilox roller for each group, adopt the anilox roller to spread ink
5. Printing unit adopt 360° For registration
6. Printing unit have one infrared to dry the device group each
8. Unwinding, printing, varnishing, IR drying, laminating and rewinding can be finished in one process, this kind of printing machine is the most suitable for each printing companies to print on adhesive-paper labels and other commercial labels.
9. The rubber roller can break away from automatically while parking, and running at a low speed, in order to avoid water being black to be dry.Main technical parameter:Model RY330 RY470
Printing speed 5-60M/min 5-60M/min
Printing color 2-6(color) 2-6(color)
Max web width 330mm 460mm
Max printing width 320mm 450mm
Max unwind diameter 600mm 600mm
Max rewind diameter 600mm 600mm
(Roll core inner diameter): 76mm(3 inch) 76mm(3 inch)
Printing girth 175-400mm 175-400mm
Overprint precision ± 0.1mm ± 0.1mm
Overall dimensions(L× W× H)
Machine weight (about)3000KG (about)3500KG
Power 380V/AC (Three-phase) 50Hz
Total power 6.8KW(UV not include UV device)
Wenzhou Qiangtuo Machinery Co., Ltd is established in 2006 and located in Wenzhou City, enjoying convenient transportation and beautiful environment. Qiangtuo Machinery is one of best comprehensive manufacturers of printing machinery and plastic machinery in China. We are with rich experiences in flexographic printing machine, gravure printing machine, film blowing machine, bag making machine and slitting machine. Our company keys to research and develop new technology to guarantee quality. Therefore, we can fully satisfy your demands and have a large customer base.
Qiangtuo company, with its professional spirits and focus attitude, strictly abides by optimized programs from material selection, production, inspection to after sales service. Every process is under strict inspection. We are based on polices of "Winning Customers Trust by Quality" and "Meeting Customers' Demands by Constant Improvement" to offer superior products service. Qiangtuo people, with our professional as well as our remarkable products quality and favorable service, sincerely hope to work together with the vast number of clients, create brilliant!
