Aws F6a0-Eh14 Fused Flux Hj-350 F6a0eh14 JIS Ysf-W41

Product Specifications

Prod Model:	HJ350 F6A0-EH14 JIS YSF-W41
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Size:	10-60mesh
PH:	Neutral
State:	Solid
Type:	Inorganic

Product Description

HJ350 is defined as fused type fluxes medium-manganese, medium-silicate and medium fluorine elements, color in brown to high yellow, with vitreous granules 8-40 meshes in size. Fluxes are suitable for use both AC and D. C. When applying D. C, filler-wire will be connected to electrode positive (EP). Fluxes have good welding technological behavior.

Field of application: Fluxes match proper filler-wire (I. E H08MnA, H010Mn2, H08Mn2 etc) of which may be use for welding of low-alloyed steel (I. E. 16Mn\15MnVN\15MnV etc) important structures for example: Ships, boilers, pressure vessels etc. As required by fine-granule fluxes, they can be used for SAW with filler-wire to serve thin-plating weld.

                               composition of fluxes(%)

SiO2	CaF2+CaO+Al2O3	S	P
44-55	37-56	≤0.06	≤0.07

       Mechanecal properties of deposited metals combined wire and flux

Wire	Yield Stress     δs Mpa	Tensile Strength       δb Mpa	Elongation      δ5%	Akv(J)
				0ºC
Guaranteed value	≥330	410-550	27≥	≥27
H10Mn2	410	524	31	110
