Backhoe Loader (WZ30-25)

Name: Backhoe Loader (WZ30-25)
Brand: China-Manufacturer-Directory.com
SKU: 667551822
Availability: InStock
Rating: 4.7 (30 reviews)

Supplier:	Shanghai Win-Win Industrial Co., Ltd.
Price:	Negotiable
Min Order:	1unit
Quantity::
Trade Terms:	FOB

Product Specifications

Prod Model:	WZ30-25
Markets:	South America,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia
Color:	Yellow & White
Engine:	Deutz Td226b( Made in China)
Drive Mode:	4WD & 2WD
Front Loader Bucket:	1 M3
Back Digger Bucekt:	0.3m3
Operation Weight:	7400kg
Braking Axle:	Italy Original Imported Carraro
Synchronization Shift, Electric-Hydrauli:	Italy Original Imported Carraro
Type:	Wheel Excavator
Type2:	Backhoe Loader

Product Description

Main Performance:
1. Backhoe loaders exclusive use chassis, compact structure, rationally distributed.
2. Equipped with totally enclosed cab with broad vision and attractive outline design, It is comfort and reasonable to control the machine with its full range and humanization design in control system.
3. Adopt the Weichai DEUTZ engine, which is green environmental protection, high power, less fuel consumption, high working efficiency, low use cost.
4. The imported professional digging/loading transmission system from Italy, and Chinese top brand hydraulic systems enable the high stability, and the machines performance could reach the international advanced level.
5. Excellent digging/loading performance brings the best return on customers investment.
6. The imported driving axle with differential lock and wet-type brake ensure the hauling ability and safety performance. Big steering angle and big oscillating angle of swing steering axle ensure the high steering ability. Driving brake and parking brake system adopt the self-regulating, full-regulating wet-type brake with free-maintenance.
7. Optional two-wheel drive or four-wheel drive could meet customers requirement.
8. Various optional tools could be equipped according to customers requirement.

Loading Performance
Mono lever controls booms rise and fall overturn of the loading bucket and the clutchs shift.
Automatic leveling system of loading bucket avoids material drops out, automatic reposition after dumping.
In-line arrangement double cylinder of the loading system has the superior breakout force. The loading bucket could completely turnover.
Digging Performance:
Spread wing style outriggers and MID-type excavating gear, with superior working stability.
Attached with different attachment, it could accomplish different operations, such as excavating, crumbling, skiving, etc.
Excavating control valve with six jumper valves, special designed buffer system, ensure the working process smoother and steadier.

Item				Unit	WZ30-25
Backhoe bucket capacity				m3	0.3
Rated loading bucket capacity				m3	1
Rated Lifting Force				kN	>25
Engines rated power/rated speed				kW	70/2200
Total operating weight				kg	7400
Backhoe turning angle		Left		º	90
Backhoe turning angle		Right		º	90
Backhoe parameter	Max. digging radius			mm	5481
	Max. dump height			mm	3737
	Radius at the max. dump height			mm	1084
	Max. digging radius at ground level			mm	5437
	Digging buckets max. rotating angle			º	163.2
	Max. digging depth			mm	4338
	Max. digging force			kN	50±10%
Loading parameter	Max. dump height			mm	2626
	Dump reach at max. dump height			mm	726(at dumping angle)
	Bucket drawback angle		Transportation position	º	43.5
	Bucket drawback angle		Ground position	º	36.5
	Dump angle			º	43.5
	Digging depth			mm	191
	Max. breakout force			kN	>40
Max. grade ability				%	>30
Max. traction power				kN	42
Gear and travel speed	Forward/Backward gear I			km/h	5.8/7.0
	Forward/Backward gear II				10.5/12.6
	Forward/Backward gear II				20.1/24.3
	Forward/Backward gear IV				40.2/48.6
Min. turning radius				mm	4300
Total length				mm	7077
Total height				mm	3424
Max. height (Cab)				mm	2735
Max. Width(outrigger)				mm	2250
Bucket width				mm	2328(with attachment) 2313(bucket max. width)
Loading Operation Specification
Rated Bucket Capacity(m³)	1
A. Max. Dumping Clearance(mm)	2612
B. Max. Dump reach(mm)	727
C. Dig depth	191
D. drawback angle at ground pos.	40°
E. Bucket upward angle at max. working height	63°
Max. breakout force	40
Rated Lifting Force	25
Rise Time	5.1
Fall Time	4.9
Tilting Time	0.9
Excavating Operation Specification
Rated Backhoe Bucket Capacity	0.3
F. Max. Digging Depth	4340
Max. Digging Force	50±10%
G. Max. Digging Radius	5482
H. Max. Dump Height	3738
I. Max. Outreach from mid. of Rear Axle mm	6583
J. Max. Outreach at the Max. Dump Height (mm)	1084
Turning Angle	180°
Engine Model	DEUTZ TD226B
Type	Four-stroke, Direct Injection type, Turbo Charge
Rated speedrpm	2200
Rated power (hp/kw)	95/70
Peak torque (N.m)	380

transmission System
Transmission		Four gear synchronization, electric-hydraulic control forward/backward. Switch, shift and loading control handle have clutch splitting key
Different Speed Lock		Button Control
Driving Break		Individual brake on left or right wheel, electric-hydraulic control, built-in wet-type brake block.
Parking Break		Mechanical control with electronic sensor
Front Axle		Swing turn, oscillating angle is 22°, optional two-wheel or four-wheel drive.
Rear Axle		Load operation handle button control the differential lock.
Min. Turning Radius at the outer of Front Wheelmm	Two-Wheel Drive	3790
Min. Turning Radius at the outer of Front Wheelmm	Four-Wheel Drive	4300
Min. Ground Clearancemm	Two-Wheel Drive	357
Min. Ground Clearancemm	Four-Wheel Drive	277
Max. Driving Force (KN)	Two-Wheel Drive	43.8
Max. Driving Force (KN)	Four-Wheel Drive	70
Travel Speedkm/h		Gear	Forward	Backward
			5.8	7
			10.5	12.6
			20.1	24.3
			40.2	48.6
