Product Specifications
| Prod Model: |
BY810B |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Silver: |
Labeling Machine, Labeling Machinery |
| Automatic Grade: |
Automatic |
| Driven Type: |
Electric |
| Packaging Material: |
Bamboo, Wood |
| Applicable Industry: |
Apparel |
| Application: |
Dairy Products |
| Type: |
Single Side Labeling Machine |
| Packaging Type: |
Export Pack |
Product Description
BY810B Single Side Labeling Machine Labeling machinery
Product features
1. Be applicable to square bottles or flat bottles in single side mark.
2. The independently shape structure is designed specially and independently to label irregular bottles in cosmetic industry. The optional air driving and roller labeling set can label round bottles precisely.
3. The shape belt can be inclined, and the labeling head can be adjusted at eight orientations, so the machine can be adjusted successfully in several minutes for any bottle.
4. The machine apply the famous server motor, so it realizes real closed loop controlling and it avoids the phenomenon of the ordinary stepper motor, high-precision refinement, built-in absolute encoder. All this is designed to improve the accuracy.
5. The shape structure is designed specially, so labeled thing is able to be located and labeled precisely.
6. The label is pressed by a flap after applying on bottle and is pressed by the active and passive sponge rollers. So when the label is stuck it hasn't any air bladder. It is especially applicable to the crystal bottles labeled with transparent labels.
|
Model |
DY810B |
|
Production speed |
40m/min(80~200pcs/min) |
|
Labeling accuracy |
±1mm |
|
Label max width |
200mm(can be raised according to the require) |
|
Label inner diameter |
Φ76.2mm |
|
Label outer diameter |
Φ350mm |
|
Was posted content size |
thickness ≤30mm height ≤500mm |
The height of the conveyor line
chain plate to the ground |
900mm±50mm(can be produced according to customer requirements) |
|
power |
380/220V ,50Hz 2300W |
|
Operating pressure |
3-5kg 30L/min |
|
Weight |
280KG |
|
size |
3048*1200*1500mm |
Guangzhou DaYuan Machinery Equipment Co., Ltd. is a professional manufacturer of labeling equipment, focusing on research and development of automatic labeling machine, manufacturing, sales and technical services. And the machine is widely used in food, beverage, pharmaceutical, liquor, daily chemicals, electronics, smart card and tobacco, and so on.
DaYuan company has professional design team, the designers and engineers have more than 10 years labeling research work experience, strong technical force. We will supply customers the complete solution, and meet the market requirement of labeling equipment currency and fast speed.
DaYuan company main sales high-speed rotary labeling machine, three header labeling machine, non-standard labeling machine, double sides labeling machine, flat labeling machine, round bottle labeling machine and horizontal small round bottle labeling machine, with its superior durability and stable performance, perfect intimate the service has won wide acclaim from users.
