Wenzhou Tosun Electric Co., Ltd. >> Ca10 Universal Changeover Switch

Ca10 Universal Changeover Switch

Name: Ca10 Universal Changeover Switch
Brand: China-Manufacturer-Directory.com
SKU: 753708225
Availability: InStock
Rating: 4.7 (56 reviews)

Supplier:	Wenzhou Tosun Electric Co., Ltd.
Price:	US $ 1.99-14.05/Piece
Min Order:	100/Piece
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	CA10 series
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Rated Insulation Voltage (V):	690
Rated Working Voltage (V):	120, 240, 440
Conventional Heating Current:	20-160 Ith(a) AC10 ≤40°
Mechanical Life:	60*10^4
Electrical Life:	AC-15 2010^4; DC-13 610^4
Rotary Number:	Single Button
Operation:	Combined
Certification:	CE
Usage:	Vehicle
Standard:	Standard
Condition:	New

Product Description

Specification

Type		CA10-20	CA10-25	CA10-32	CA10-63	CA10-125	CA10-160
Rated insulation voltage ui(V)		690	690	690	690	690	690
Conventional heating current ith(A) Ac 10<=40°		20	25	32	63	125	160
Rated working voltage ue(V)	120 240 440	120 240 440	120 240 440	240 440	240 440	220 440
Rated working current le(A)	AC-21A AC-22A	20 20	25 25	25 32 32	63 63	100 100	150 150
	AC-23A	15 15	22 22	22 30 30	57 57	90 90	135 135
	AC-2	15 15	22 22	22 30 30	57 57	90 90	135 135
	AC-3	11 11	15 15	15 22 22	36 36	75 75	95 95
	AC-4	3.5 3.5	6.5 6.5	6.5 11 11	15 15	30 30	55 55
	AC-15	5 4	8 5	5 14 6
	AC-13	5 1	9 1.5	25 11
Rated control power(KW)	AC-23A	3.7/2.5 7.5/3.7	5.5/3 11/5.5	7.5/4 15/7.5	15/10 30/18.5	30/15 45/22	37/22 75/37
	AC-2	4 7.5	5.5 11	7.5 15	18.5 30	30 45	37 55
	AC-3	3/2.2 5.5/3	4/3 7.5/3.7	5.5/4 11/5.5	11/6 18.5/11	15/7.5 30/13	22/11 37/18.5
	AC-4	0.55/0.75 1.5/1.5	1.5/1.1 3/2.2	3.7/15 5.5/3	5.5/2.4 7.5/4	6/3 12/5.5	10/4 15/7.5
Mechanical life		60 x 10^4
Electrical life		AC-15 20 x 10^4 DC-13 6 x 10^4

Why us?
1. We have extensive experience in low tension electric items and illumination products, because we have been dealing the line for more than 24 years.

2. The prices of our products are very reasonable because we have a good network of raw material supply, spare parts and goods. And our factory is efficient, covering an area of 13,000 m².

3. The quality of our products are reliable because we have a group of professional inspectors supervising the quality during the production and before shipment. Our products have obtained TUV, SEMKO, CE, CB, and ROHS certificates.

4. The packing of our products is attractive because we have particular designers in charge of packing material in a unique style.

5. The service from our company is favorable, because we have experienced salesmen to handle business for you specially.

We are one of the most reliable manufacturers and exporters of low tension electrical items and illumination products in China. We have successfully developed and dealt with numerous electrical products in high quality, such as Circuit Breaker, AC Contact, Panel Enclosure, Electrical Accessories for Panel Enclosure, Pushbutton, Switch, Fuse, Meter, Temperature Controller, Cable Tie, Wiring System products as well as illumination items.

· Qualifications and Technological Strength

We possess full line of high-tech production equipment and great strength of technology support besides advanced designing forces powered by the first class engineering teams with super industrial computer systems. Thus, Our products are novel in designs, excellent in workmanship and tope reliable in quality. A lot of our products have obtained "RoHS", "CB", "CE" and "IRAM", and other international quality approvals. The products now are being well sold in more than 82 countries and regions in the world.

· Contact Us Today

We have always pays special attention to protecting the benefits of clients' so that both the clients ans our company are able to gain the maximum benefits from the relations between us. We warmly look forward to establishing, reinforcing and expanding long term fruitful relationship with the reliable clients all over the world.

Let's get busy and pull together to create a better future.
