Product Specifications
Prod Model: |
yx |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Composition: |
Permanent |
Type: |
Bobbin |
Structure: |
Coil Bobbin |
Product Description
Bobbin PQ (Coil Bobbin)
General Introduction
1, Bobbin PQ conformation is horizontal with through-holes; Bobbin is made of thermoset and thermoplastic
2, The coilformers are made in gfr Polyamide PA66 of type p6g (RTI long-range temperature +125 centigrade degree). Pin material is tin bronze, tinned for solder-pins and brass, tinned for solder-tags. Max. Solder temperature +350centigrade degree
3, The coilformers are suitable for automatic winding on computer controlled machines
4, Surface mount is not available. Large terminals allow larger diameter magnet wire
Applications:
Bobbin PQ Series are for Ferrite Core used in Switching Power Transformers, Switch Transformer, Inductor, Coil, Filter, etc.
Grade | Max. Operational temperature |
N35, N38, N40, N42, N45, N48, N50, N52 | 80° c |
N33SH, N35SH, N38SH, N40SH, N42SH | 150° c |
N28UH, N30UH, N33UH, N35UH, N38UH | Up to 180° c |
N28EH, N30EH, N33EH, N35EH | Up to 200° c |
N30AH, N33AH, N35AH | Up to 230° c |
For more detail info, please feel free to visit our website or inquire us at any of your convenience.
Ying Jun
Senior technical manager
Yuxiang Magnetic Materials Ind. Co., Ltd
Add: Floor 16, Jinyuan plaza, # 57 Hubin Nan Road, Xiamen, China 361004
Mobile: +86 13850003134
TEL: 0086-592-2295387/2217138
FAX: 0086-592-2222216
(E-mail): mag(a)e-magnet(.)cn
Xiamen Yuxiang Magnetic Materials Ind. Co., Ltd. is located in the beautiful coast of southeast sea. Established in 1997, we are an export-oriented enterprise. Now our company becomes an enterprise with advanced technology, owning two factories in China, both of which have their own R&D and QC departments, and are ISO9001: 2000 certified. We also have an office in Xiamen to provide you with prompt export support.
We are moving ahead with the aim of producing more advanced, more practical, and more competitively-priced products. We keep close track with the ever-changing trends in the industry, with the objective of spearheading our company in the market. We have an ambitious outlook towards expansion, and operate our business with diligence and sincerity. Our more than 20 years of technical know-how and experience have been keeping us ahead in the industry. We have been in the OEM business for five years and are ready for your orders and special requirements.
We supply hard magnets and magnetic materials from China. Our magnets include ferrite magnets, flexible magnets, NdFeB magnets, AlNiCo magnets, SmCo magnets, rubber magnets, refrigerator fridge magnets, magnetic powder, magnetic compound tesla meters & magnetizers, and magnetic jewelry. We also supply ferrite cores, MnZn cores and NiZn cores for transformers and coils, loudspeaker magnets, motor magnets, and refrigerator gasket stripes.
