Ckj5-400 AC Big Current Low Voltage Vacuum Contactor with CE

Name: Ckj5-400 AC Big Current Low Voltage Vacuum Contactor with CE
Brand: china-manufacturer-directory.com
SKU: 770951225
Availability: InStock
Rating: 4.3 (107 reviews)

Supplier:	Yueqing Winston Electric Co., Ltd.
Price:	US $ 204-254/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	CKJ5-400
Markets:	North America,South America,Eastern Europe,Africa,Oceania,Eastern Asia,Western Europe
Brand:	Winston
Number Of Contact:	3no+3nc
Case Color:	Orange, Grey, Red
Service:	OEM, ODM
Warranty Of Contactor:	2 Years
Condition:	Original New
Size:	Miniature
Usage:	Household Appliances Relay, Communication Relay, Lathe Relay
Action Principle:	Electromagnetic Type
Theory:	Vacuum Contactor

Product Description

Product Description

Vacuum contactors utilize vacuum bottle encapsulated contacts to suppress the arc. This arc suppression allows the contacts to be much smaller and use less space than air break contacts at higher currents. As the contacts are encapsulated, vacuum contactors are used fairly extensively in dirty applications, such as mining.
Vacuum contactors are only applicable for use in AC systems. The AC arc generated upon opening of the contacts will self-extinguish at the zero-crossing of the current waveform, with the vacuum preventing a re-strike of the arc across the open contacts. Vacuum contactors are therefore very efficient at disrupting the energy of an electric arc and are used when relatively fast switching is required, as the maximum break time is determined by the periodicity of the AC waveform.
characteristics

Model	Rated Voltage		Rated Current	Main contact parameters			Frequency voltage (V) (RMS)
	Rated Voltage		Main Electric Circuit	Main contact parameters			Frequency voltage (V) (RMS)
	Main Electric Circuit	Control electric circuit	(A)	contact distance(mm)	contact overtravel(mm)	contact pressure(mm)	Main Electric Circuit	Auxiliary circuit	Control electric circuit
CKJ5-63/1140	1140	36,110,220,380	80	1.8±0.2	>1	30±5	4200	2500	2000
CKJ5-125/1140	1140	36,110,220,380	125	1.8±0.2	>1	30±5	4200	2500	2000
CKJ5-160/1140	1140	36,110,220,380	160	1.8±0.2	>1	30±5	4200	2500	2000
CKJ5-250/1140	1140	36,110,220,380	250	2±0.2	>1.5	80±10	4200	2500	2000
CKJ5-400/1140	1140	36,110,220,380	400	2+0.5/0	>1.5	120±20	4200	2500	2000
CKJ5-630/1140	1140	36,110,220,380	630	2+0.5/0	>1.5	190±20	4200	2500	2000
CKJ5-800/1140	1140	36,110,220,380	800	2+0.5/1	>1.5	190±20	4200	2500	2000
CKJ5-1000/1142	1140	36,110,220,380	1000	2+0.5/2	>1.5	190±20	4200	2500	2000

Model	making capacity	breaking capacity	Breaking Current(A)	Electric life time		Mechanical life	Weight
Model	making capacity	breaking capacity	Breaking Current(A)	AC3	AC4	Mechanical life	Weight
CKJ5-63/1140	10Ie,100Times	8Ie,25Times	2000,3Times	60×104	6×104	300×104	3.8kg
CKJ5-125/1140	10Ie,100Times	8Ie,25Times	2000,3Times	60×104	6×104	300×104	3.8kg
CKJ5-160/1140	10Ie,100Times	8Ie,25Times	2000,3Times	60×104	6×104	300×104	3.8kg
CKJ5-250/1140	10Ie,100Times	8Ie,25Times	4500,3Times	60×104	6×104	300×104	8kg
CKJ5-400/1140	10Ie,100Times	8Ie,25Times	4500,3Times	60×104	2×104	300×104	11.3kg
CKJ5-630/1140	10Ie,100Times	8Ie,25Times	6000,3Times	60×104	0.5×104	300×104	19.5kg
CKJ5-800/1140	10Ie,100Times	8Ie,25Times	7200,3Times	60×104	0.5×104	300×104	20.5kg
CKJ5-1000/1140	10Ie,100Times	8Ie,25Times	8500,3Times	60×104	0.5×104

PS:If you can't find the exact type of your product.Please don't rush to go away.Contact me and your questions will be replied ASAP.Thank you for your time.
