Shenzhen Mountain A-Li Group Electronic Technology Co., Ltd. >> Clear Animation Effect Full Color LED Indoor P6 Display

Clear Animation Effect Full Color LED Indoor P6 Display

Name: Clear Animation Effect Full Color LED Indoor P6 Display
Brand: china-manufacturer-directory.com
SKU: 746708295
Availability: InStock
Rating: 4.9 (61 reviews)

Supplier:	Shenzhen Mountain A-Li Group Electronic Technology Co., Ltd.
Price:	US $ 600-700/Square Meter
Min Order:	1/Square Meter
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	P6 indoor led display
Markets:	South America,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia
Module Size:	192X192mm
Brightness:	>3000CD/M2
Cabinet Size:	576X576mm
Working Voltage:	220VAC
Optimal Viewing Distance:	6-40m
Optimal Viewing Angle:	160°(W) 120°(H)
Control Mode:	Synchronization with PC
Mtbf:	>9,000hours
Cabinet Pixel:	96X96dots
Certificate:	CE&RoHS
Tube Chip Color:	Full Color
Display Function:	Video Display
Pixel Pitch:	6mm
Pixel Configuration:	1R,1G,1B
Pixel Density:	27,777 dots / m²
Scanning Mode:	1/4 Scan
System Operating Platform:	WIN XP
Display Type:	LED Video Display
Application:	Advertising
Certification:	FCC,EMC
IP Rating:	IP31

Product Description

Clear Animation Effect full color LED Indoor P6 Display

Product Features
Energy saving design, good cooling system, high definition,
Cost-effective, outstanding reliability, complete function,
Are favorite by new and old customers
Ultra-high refresh rate, can support video shooting,
Clear picture quality assurance
Quick and easy assembly, removing System, save loading time

Using Range
Widely used in large venue, stadiums, bank, government,
Terminal, dock, station, stock market, medical systems,
Electricity, exhibition etc.

Item	Parameter
Product model	P6-4S	P6-8S
Module size	192mm*96mm
Pixel pitch	6mm
Pixel density	27777dots/m2
Pixel configuration	smd 3in1
Module resolution	32dots(W)*16dots(H)
Maximum power consumption	15W	12W
Module thickness	14.85mm
Module weight	0.154kg
Driving method	Constant current driving
Scan mode	1/4 scan	1/8 scan
Interface type	HUB75-A
Brightness	≥ 3000cd/m2	≥2200cd/m2
The specifications of cabinet

Cabinet size	576mm*576mm
Module quantity	18pcs
Power supply	5V/40A *2pcs
Cabinet resolution	96*96dots
Optimal viewing distance	6m ~ 40m
Optimal viewing angle	160°(W) 120°(H)
System operating humility	10%-95%
The specifications of power supply

Operating voltage	AC220V±10%
Average power consumption	270W/ m2	220W/ m2
Maximum power consumption	≤ 810W/ m2	≤3650W/ m2
Current	≤20mA(single LED)
The specifications of control system
Computer	Pentium4 or above
Operating system	WIN98/2000/NT/XP
Control model	Synchronization control
The specifications of the main technical parameters

Driving device	Constant current driving
Refresh rate	≥400Hz
Grey scale	RGB each 256 grade, can display 16.7M colors)
MTBF	≥9000hours
Power switch	Automatic switch
Display mode	800600/1024768

Shenzhen Mountain A-Li Group Electronic Technology Co., Ltd Major In LED Modules and LED Display. Indoor LED Display have P3 P4 P5 P6 P7.62 P10 (Have difference cabinets types ). Outdoor have P6 P7 P8 P10 P16 (Have difference cabinets types ), LED Modules have single color, double color and full color, LED Display Have Indoor LED display, Outdoor LED display, Outdoor LED screen. Indoor LED screen, LED video display, LED Video screen, LED Advertising screen, LED Advertising Screen.

Features:

1) With good lightening accordance and no mosaic

2) LED advertising board can play different formats of image files, flash, WAV/MIDI, video signal from TV, video signal from video and other equipment

3) Different video frequency can be changed freely at the same time, and the image can be enlarged and reduced

4) High brightness, and can be adjustable, meets the need of changing requirement of customer in environment

5) Uses real pixels rather than virtual pixels, better viewing effect

Applications:

LED advertising board wide applied in stadiums, advertising, banks, securities exchange, stations, shopping malls, postal offices, schools, monitoring, restaurants, entertainment, enterprises etc
