Product Specifications
| Prod Model: |
CK6150 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Max. Swing Over Bed: |
500mm |
| Max. Rotative Diameter On Carriage: |
250mm |
| Max Processing Length: |
1800 Mm |
| Spindle Nose: |
1: 20 |
| Spindle Step: |
Step-Less |
| Through-Hole Dia. Of Drawn Pipe: |
41mm |
| Spindle Speed Range: |
850-2000 Rpm |
| Main Motor Power: |
7.5kw |
| Tailstock Sleeve Diameter: |
75mm |
| Tailstock Sleeve Travel: |
200mm |
| Type: |
Horizontal Lathe |
| Automatic Grade: |
Automatic |
| Precision: |
High Precision |
| Power Source: |
Electric |
| Setting Mode: |
Floor-type |
| Controlling Mode: |
CNC |
| Processing Accessory: |
Chuck CNC Lathe |
| Tool Holder: |
Single-tool Holder CNC Lathe |
| Certification: |
ISO14001 |
Product Description
1. standard accessories
| 1 | CK6150 cnc lathe machine |
| 2 | controller |
| 3 | manual chuck 10" |
| 4 | 4 station electric tool holder |
| 5 | Full set coolant system |
| 6 | Full set lubrication system |
| 7 | Work light |
| 8 | Tools and tool box |
| 9 | MPG |
2. optional accessories
| 1 | Auto bar feeder |
| 2 | Manual tailstock and rotary center |
| 3 | Hydraulic chuck |
| 4 | Hydraulic station and cylinder |
| 5 | 8 tool electric tool carrier |
| 6 | Chip conveyor |
3. Payment terms: 30 % T/T, and the balance before delviery.
Warranty:12 months
Delivery: 7-15 working days
Shandong Pulute Machine Tool Co., Ltd. is a high-tech enterprise integrating design, development, manufacturing and marketing of products. We are mainly engaged in production and operation of CNC lathe, engraving and milling machine, gantry machine. All of our products comply with international quality standards such as CE and are greatly appreciated in a variety of markets around the world. Besides, we have received ISO9001: 2008 and ISO14001: 2004 certification.
Shandong Pulute Machine Tool Co., Ltd. is located in Tengzhou, Shandong, with convenient transportation. Covering an area of 120000 square meters, there are over 200 employees and an annual sales figure that exceeds USD20 million. Currently 30% of our products are exported worldwide. Factory with well-equipped facilities and excellent quality control throughout all stages of production enables us to guarantee total customers satisfaction.
