Comfortable Running Control Elevator

Comfortable Running Control Elevator
Supplier: Zhejiang Sicher Imp. & Exp. Co., Ltd.
Price: US $ 17000/Piece
Min Order: 1/Piece
Quantity::
Trade Terms: FOB
contact supplier

Product Specifications

Prod Model: GRPS20
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Inverter: Vvvf
Features: Saving Space
Running: Stable
Product Name: Space Saving Machine Roomless Passanger Lift
Persons: 11 - 19
Speed: 1.00 - 2.00m/s
Capacity: >1000kg
Type: Passenger Elevator
Driving Type: AC Elevator

Product Description

1. Passenger lift
2. VVVF
3. EN115
4. Different choices & prices
5. Steady running

Standard Function
Travel function
VVVF drive
Motor rotating speed can be precisely adjusted to get smooth speed curve in lift start, travel and stop and gain the sound comfort.

VVVF door operator
Motor rotating speed can be precisely adjusted to get the more gentle and sensitive door machine start / stop.

Reopen with hall call
In the door shutting process, press reopen with hall call button can restart the door.

Car stops and door open
The lift decelerates and levels, the door only opens after the lift comes to a complete stop.

Automatic returning to the base station
When the traffic flow is low, lift without receiving commanding signals will automatically return to the base floor and standby with the door closed.

Automatic pass without stop
When the car is crowded with the passengers or the load is close to preset value, the car will automatically pass the calling landing in order to keep maximum travel efficiency.

Protection
Down over-speed protection device
When the lift downs 1.2 times higher than the rated speed, this device will automatically cut off control mains, stop the motor running so as to stop lift down at over-speed. If the lift continues to down at over-speed, and the speed is 1.4 times higher than rated speed, safety tongs act to force the lift stop in order to ensure the safety.

Upward over-speed protection device
When the lift up speed is 1.2 times higher than rated speed, the device will automatically decelerate or brake the lift.

Photocell protection
In the door open and shut period, infrared light that covers the whole door height is used to probe the door protection device of both the passengers and objects.

Traffic lights
Red / green traffic lights are available in the hoist-way door to properly dispatch the vehicles.
Emergency function
Emergency car lighting
Emergency car lighting automatically activated once power failure.

Five way intercom
Communication amid car, car top, lift machine room, well pit and rescue duty room through walkie-talkie.

Bell
In emergency conditions, if bell button above car operation panel is continuously pressed, electric bell rings on top of the car.

Fire emergency return
If you start key switch in main landing or monitor screen, all the callings will be cancelled. The lift directly and immediately drives to the designated rescue landing and automatically opens the door.
Man-machine interface

Micro-touch button for car call and hall call
Novel micro-touch button is used for operation panel command button in the car and landing calling button.

Floor and direction indicator inside car
The car shows the lift floor location and current travel direction.

Floor and direction indicator in hall
The landing shows the lift floor location and current travel direction.

Energy-saving function

Car ventilation,

Light automatic shut off
If there is no calling or command signal within the stipulated time, the car fan and lighting will be automatically closed in order to save the energy.

Remote shut-off
The lift can be called to main landing (after finishing the service) through the key switch and automatically exists the service.

We apply the advanced micro-processing network control technology for Rhine GRP20 passenger lift. High performance CPU and large capacity storage space, CAN-BUS serial communication produce the extremely strong anti-interference capabilities and perfect lift operation functions. The users can increase special functions according to the specific needs.

At present, the modular; Intelligent and extensive system, multi-functional serial interface, long-distance monitor technology etc. Belong to the advanced control technology in the lift industry.
Zhejiang Sicher Imp. &Exp. Co., Ltd. is founded and invested by Sicher Elevator Co., Ltd. (former: Rhine Lift (China) Co., Ltd. ), a branch company of Sicher Group specializing in the foreign trade business of Sicher Group products. Sicher team is a professional team with many years experience in the international business.

Zhejiang Sicher Imp. &Exp. Co., Ltd. Adheres to the rigorous, pragmatic, study and innovative spirits. It adopts the service idea of "customers' interest supreme" and is dedicated to provide service all around the world.

The products of Sicher Group ranges from elevators, escalators, car parking system, solar photovoltaic system and solar module, electronic products, stationery sports goods, crafts and gifts, etc.

Among Rhine Group, the new factory of Sicher Elevator Co., Ltd. (former: Rhine Lift (China) Co., Ltd. ) covers the area of 147, 600 square meters with the total yearly capacity of 40, 000 sets elevators, escalators, three dimensional parking system. It has a product R&D center and the enterprise technology center, as well as an elevator experiment towers with height of 108 meters and the maximum speed 8.0m/s_for the purpose of researching and developing the super velocity, large capacity high-end elevator product and technology. The company products strictly meet the European standards of EN115, EN81, and get ISO9001, ISO14001 international authentication, TUV and the European Union CE product certificates issued by Germany Engineering supervision Association, as well as OHSAS18001; It also has the highest rank of manufacture permit in the domestic elevator industry, A level permit of installation, reconstruction and maintenance, as well as own technical invention patent of elevator products.

"SRH - Olny For Safe Reach" is our eternal principle. Welcome customers all over the world to visit and cooperate with us and establish long-term business relationship.
